TB 108 Hybrid Takeuchi excavator specs & dimensions (2012 - 2016)

Takeuchi TB 108 Hybrid is a mini excavator manufactured from 2012 to 2016, with a weight of 0.95 t. It features a track width of 1…

Takeuchi TB 108 Hybrid is a mini excavator manufactured from 2012 to 2016, with a weight of 0.95 t. It features a track width of 180 mm and a transport width of 0.9 m. The maximum bucket capacity is 0.1 m³. Special equipment includes a blade, rubber track, and track adjustment.

Mini Excavators Takeuchi TB 108 Hybrid
Mini Excavators Takeuchi TB 108 Hybrid
Mini Excavators Takeuchi TB 108 Hybrid
Mini Excavators Takeuchi TB 108 Hybrid
Mini Excavators Takeuchi TB 108 Hybrid
Mini Excavators Takeuchi TB 108 Hybrid

Technical specs - TB 108 Hybrid Takeuchi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
0.95 t
Transport width
0.9 m
Bucket capacity max.
0.1 m³
Track width
180 mm
Driver protection
FD
Max. Reach horizontal
2.03 m
Model series
TB
Engine manuf.
Yanmar
Engine type
2TNV70
Engine power
7.6 kW
Displacement
0.57 l
Revolutions at max torque
2300 rpm
No. of cylinders
2

More technical details, like: transport length, transport height, bucket capacity, bucket capacity min., bucket width, standard tyres, dredging depth, tear-out force, dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Takeuchi TB 108 Hybrid FAQ

When was the Takeuchi TB 108 Hybrid manufactured?

The Takeuchi TB 108 Hybrid was manufactured from 2012 to 2016.

How much does the Takeuchi TB 108 Hybrid weigh?

The Takeuchi TB 108 Hybrid weighs 0.95 tons.

What is the transport width of the Takeuchi TB 108 Hybrid mini excavator?

The transport width of the Takeuchi TB 108 Hybrid mini excavator is 0.9 meters.

What is the track width of the Takeuchi TB 108 Hybrid mini excavator?

The Takeuchi TB 108 Hybrid has a track width of 180 mm.

What is the maximum horizontal reach of the Takeuchi TB 108 Hybrid mini excavator?

The Takeuchi TB 108 Hybrid mini excavator has a maximum horizontal reach of 2.03 meters.

What is the maximum bucket capacity of the Takeuchi TB 108 Hybrid mini excavator?

The maximum bucket capacity of the Takeuchi TB 108 Hybrid mini excavator is 0.1 cubic meters.

What operator safety and support features does the Takeuchi TB 108 Hybrid have?

The Takeuchi TB 108 Hybrid provides operator safety with a canopy for driver protection.

How much is a Takeuchi TB 108 Hybrid Mini excavator (2012u20132016) worth?

The residual value of the Takeuchi TB 108 Hybrid depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
