JCB 8029 CTS excavator specs (2019 - 2022)
Check out detailed specifications, information and technical data for JCB 8029 CTS excavator manufactured between 2019 - 2022. Get... Read more
Check out detailed specifications, information and technical data for JCB 8029 CTS excavator manufactured between 2019 - 2022. Get more in-depth insight with JCB 8029 CTS digger specifications. See information, like: Weight: 2.86t – Transport length: 4.1m – Transport width: 1.55m – Transport height: 2.4m – Track width: 250mm – Max. Reach horizontal: 4.49m and more.
Technical specs - 8029 CTS JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.
- Weight 2.86 t
- Transport length 4.1 m
- Transport width 1.55 m
- Transport height 2.4 m
- Track width 250 mm
- Max. Reach horizontal 4.49 m
- Dredging depth 2.74 m
- Engine manuf. Perkins
- Engine type 403F-I5
- Engine power 18.4 kW
- Displacement 1.49 l
- Revolutions at max torque 1800 rpm
- Max. torque 80 Nm
- Emission level Tier 4F
-
Bucket capacity
### -
Bucket capacity min.
### -
Bucket capacity max.
### -
Bucket width
### -
Standard tyres
### -
Driver protection
### -
Tear-out force
### -
Dimension lxwxh
### -
No. of cylinders
### -
Cylinder bore x stroke
###
Basic model with standard bucket
Special equipment
- Track adjustment
- Rubber track
- Blade
- Aircondition
- Quick hitch hydr.
- Quick hitch mech.
Carbon footprint calculation
Calculate the carbon footprint of the JCB 8029 CTS per hour of use:
Or go directly to ERA Equipment CO2 Calculator
service provided by
Download datasheets (PDF)
JCB 8029 CTS overview
-
JCB 8029 CTS features overview
Higher, further, deeper
1 Our Maxi-Lift dozer handle allows extra lifting height even when the dipper is in maximum reach. It also offers excellent load hold performance. 2 82% better lifting capacity over the tracks (at maximum reach @ ground level) compared to the ZTS due to the repositioned centre of gravity and extra 181⁄2 single tails
Livelink tracks the efficiency of each machine, giving you the best value for money. Manage your fleet anywhere, drive down costs, improve productivity, fuel level and consumption, customer specific reports on day / week / month -
Engine / Driveline and transmission
Power, performance and stability
5 The heart of the 8029 is a 24.7 hp (gross) T4i engine with high torque of 21,581 lbf at 1800rpm for ultimate power and efficiency. 6 A solid, sturdy work platform improves productivity, versatility and operator confidence. 6 Impressive bucket and dipper tearing performance (5,170 lbf respectively 3,822 lbf) coupled with fast cycle times results in more done, faster. 6 Superior boom geometry and field elevation provide improved ground retention and the ability to slide up to dozer material. -
Hydraulics
Versatility
7 A new hand-guided tool circuit option means that the 8029 can power a wide range of JCB hydraulic tools; from breakers and drills via pumps and cutters. 8 26% more auxiliary flow than the competitor provides ultimate attachment performance. 9 The bucket-to-grab changeover option switches oil flow from bucket cylinder to an additional set of quick change auxiliary connectors, as well as versatility into specialized attachments such as suspended rotating grapples. 8029 CTS COMPACT EXCAVATOR -
Environment
Comfort and visibility
4 Large lockable toolbox provides a cluttered free working area. 2 Our electro proportional auxiliary thumb control option on the right joystick puts precision control of hydraulic attachments at your fingertips. 3 The new hydraulic system results in smooth, controlled, precise and balanced operation of excavator functions via low effort servo joysticks. 5 Large spacious operating environment with 2nd extra legroom compared to ZTS models. 5 Foldable tracking pedals keep ground level clear simplifying cab cleaning and access. 6 Large glass surfaces and a low hood profile give excellent all-round visibility, including front right track. -
Tyres / Tracks
High-strength undercarriage
1 The high-quality 10 in. wide tracks on the 8029 with locking links perform during toughest applications. 2 High-strength track legs feature three-piece manufacturing to maximize rigidity and improve track retention. Tamped edges reduce chipping holding capacity and facilitate cleaning of undercarriage.The 8029's open rail frame design also prevents buildup of loot. 3 Our new undercarriage features a top mounted roller enhancer for route durability. 4 box section dozer arms provide ultimate strength and robustness for all dozer tasks. 8029 CTS COMPACT EXCAVATOR
Precision control
1 The 8029 features a two-speed tracking button on the dozer lever, which is easy and intuitive to operate. -
Other features
WHATEVER YOU NEED AND WHEREVER YOU ARE, JCB'S DEPENDABLE NORTH AMERICAN DEALER NETWORK IS HERE TO MAKE SURE YOUR MACHINERY PERFORMS TO ITS FULL POTENTIAL.
3 JCB Yellow Shield offers comprehensive extended warranties and service agreements, as well as maintenance or repair contracts. JCB Maintenance teams offer competitive work rates and non-obligation quotes. 1 JCB Technical Support Service provides instant access to factory expertise day through night. JCB Finance and Insurance companies' teams are available at all times to provide fast, flexible competitive conditions. 2 The global network of JCB Part Centers is a model for efficiency. With 16 regional bases, we can deliver around 95 percent of all parts anywhere in the world within 24 hours. JCB genuine parts are designed to work in perfect harmony with your machine for optimum performance and productivity. -
Safety
Safe and sound
All services of 8029, including tracking and dozer, are isolated when the control pod is raised. 11 The optional JCB impact guard front screen shields the operator from flying debris when using breakers. 12 Optional boom and cab work lights for maximum protection in hazardous applications.
