8025 ZTS JCB excavator specs & dimensions (2017 - 2020)

Easy to maintain.
3 All cabs are ROPS and TOPS compliant with optional protection according to Stage 1 & 2 FOPS. Other optional front guarding devices provide peace of mind for operators, while outriggers and optional cabin work lights protect vulnerable components in hazardous applications. 4 True ZTS design provides greater safety by reducing the risk of impact on tight working areas. 5 For safer lifting operations, an boom, dozer and dipper hose breakout test valves are available as option. 6 Gullwing hoods allow easy access to all service points and 500-hour engine oil service intervals. High levels of engine filtration prevent blockages and stops. You can check the oil from ground level, the fuel filter system features a combined sedimenter, filter and priming that allows you to exhaust the system when it no longer exists, and you can change the filter without additional tools. The valve block is located sideways, which makes replacement of hoses easier plus inside the driver's house removable plastic floor plate gives clear access to the rotary motor, rotational linkage and hydraulic valve joint.

Componentry.
4 Powerful engine coupled with a variable displacement pump provides plenty of digging power. While a two-speed tracking motor, excellent tractive force and traction. 5 These machines also feature optional hose space test valves so that these excavators can comply with the laws for lifting more than 1 tonne. 6 Hydraulic system features state-of-the-art industry technology O-Ring Face Seal (ORFS) hydraulic fittings offer excellent sealing capabilities. The 8025 is light enough to be hauled behind a 3500kg drag content vehicle. Depending on local regulations/machine specifications, trailers as well as attachment configurations. PRODUCTIVITY AND PERFORMANCE 8025, 8030, 8035 ZTS MINI EXCAVATORS

THE 8025, 8030, 8035 ZTS MINI EXCAVATORS OFFER TRUE ZERO TAILSWING AND RECOGNISE THE NEED FOR EVER-MORE-COMPACT MACHINES THAT STILL DELIVER SPEED, POWER AND PRODUCTIVITY. YET THEY NEVER COMPROMISE ON EASE OF OPERATION AND CONTROL.
We know from your feedback that these minis can be more than competitive, especially in terms of stability and performance.
ZERO TAILSWING MODELS ALWAYS HAVE AN ADVANTAGE OVER CONVENTIONAL MODELS WHEN IT COMES TO VISIBILITY. IN FACT, THE SAFETY BENEFITS OF THE ZTS DESIGN MEANS IT IS NOW PREFERRED BY SAFETY OFFICERS. AND IN SOME APPLICATIONS, SUCH AS ON HIGHWAYS WHERE WORKING WITHIN ONE LANE WIDTH IS VITAL, ONLY ZTS MODELS ARE NOW SPECIFIED.
All machines feature short-distance joysticks, the most advanced micro technology in the valve block and a variable flow hydraulic pump. These provide smooth, precise control that the novice needs without compromising on the power and speed demanded by professional users.

Reliability built in.
1 The undercarriage provides optimum protection against job site damage. And the sloping track frame helps prevent dirt build-up. 2 excavator hoses are routed over the boom to provide maximum protection from damage. 3 Simple design and durable components ensure built-in reliability. 8025, 8030, 8035 ZTS MINI EXCAVATORS
Power and stability.
7 All machines feature excellent digging performance, providing impressive tear-out forces and high tractive force. 8 Stability is vital on ZTS machines, so we have worked closely with the undercarriage of these models to ensure they provide you with the safest platform for tough work. Travel dimensions are optimized to guarantee good stability both in line as well as at the sides of tracks, plus easy maneuvering and low effi ciency turns possible. 9 ZTS offers more manoeuvrability (especially in confined spaces) because there's no overhang on the rails. 8025, 8030, 8035 ZTS MINI EXCAVATORS
Dozer.
10 The unique JCB dozer design also features an improved curved profile on the front, which molds material into a roll that then moves away from the machine and does not build up and act as an obstacle. H-frame undercarriage design (as well as more rigid) also has many inclines and exit points to ensure materials beneath the machine don't rebuild and hinder performance. Undercarriage are matched with digging handling for stability and performance.
Ease of use.
1 The view from the working position is excellent. On the left you can see the entire track. Right and rear gives an improved view of the curved engine bonnet style on all machines. The hose guide profile at the top of the boom instead of side also means that there are less to hinder, as well as the large front. 2 Once in operation, the efficient heating system allows you to maintain a highly comfortable temperature. You can effortlessly store the gas-strut assisted upper front screen overcovering; furthermore, it's possible to take advantage of the lower front screen too. In addition, the whole cab structure is isolated from the slew frame for minimal vibration. 8025, 8030, 8035 ZTS MINI EXCAVATORS

JCB'S WORLDWIDE CUSTOMER SUPPORT IS FIRST CLASS. WHATEVER YOU NEED AND WHEREVER YOU ARE, WE'LL BE AVAILABLE QUICKLY AND EFFICIENTLY TO HELP MAKE SURE YOUR MACHINERY IS PERFORMING TO ITS FULL POTENTIAL.
1 Our Technical Support Service provides instant access to factory expertise day or night, while our Finance and Insurance teams are always available to provide fast, flexible as well as competitive quotes. 2 The JCB Part Centres global network is another model of efficiency; with 15 regional bases we can deliver around 95% of all parts anywhere in the world within 24 hours. JCB's genuine parts are designed to work in perfect harmony with your machine for optimum performance and productivity. 3 JCB Premier Cover offers comprehensive extended warranties and service agreements along with maintenance/repair and maintenance contracts. Irrespective of what you decide, our Maintenance Teams worldwide charge competitive working rates offering non-obligation quotations plus quick, efficient insurance repair jobs.
