60C-2 JCB excavator specs & dimensions (2021 - 2026)

JCB 60C-2 is a mini excavator manufactured since 2021, with a weight of 5.6 tons. It features a track width of 400 mm, a transport…

JCB 60C-2 is a mini excavator manufactured since 2021, with a weight of 5.6 tons. It features a track width of 400 mm, a transport length of 5.49 meters, a transport width of 1.95 meters, and a transport height of 2.56 meters. The machine has a tear-out force of 42 kN, a dredging depth of 4.08 meters, and a maximum horizontal reach of 6.14 meters. Special equipment includes air conditioning, a blade, and rubber tracks.

Visit JCB live at

60C-2

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - 60C-2 JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.6 t

Transport length: 5.49 m

Transport width: 1.95 m

Transport height: 2.56 m

Track width: 400 mm

Driver protection: Kb

Max. Reach horizontal: 6.14 m

Dredging depth: 4.08 m

Tear-out force: 42 kN

Engine manuf.: Perkins

Engine type: 403J-17

Engine power: 34 kW

Displacement: 1.663 l

Revolutions at max torque: 1600 rpm

No. of cylinders: 3

Emission level: V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

JCB 60C-2 FAQ

When was the JCB 60C-2 manufactured?

The JCB 60C-2 was first produced in 2021.

How much does the JCB 60C-2 mini excavator weigh?

The JCB 60C-2 mini excavator weighs 5.6 tons.

What are the transport dimensions of the JCB 60C-2 mini excavator?

The JCB 60C-2 has a transport length of 5.49 meters, a transport width of 1.95 meters, and a transport height of 2.56 meters.

What is the track width of the JCB 60C-2 mini excavator's undercarriage?

The JCB 60C-2 mini excavator has a track width of 400 mm.

What are the excavation performance specifications of the JCB 60C-2 mini excavator?

The JCB 60C-2 mini excavator has a dredging depth of 4.08 meters and a maximum horizontal reach of 6.14 meters.

What is the tear-out force of the JCB 60C-2 mini excavator?

The JCB 60C-2 mini excavator has a tear-out force of 42 kN.

What operator safety and support features does the JCB 60C-2 have?

The JCB 60C-2 has a cabin for driver protection.

How much is a JCB 60C-2 Mini excavator (2021u20132025) worth?

The residual value of the JCB 60C-2 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

JCB 60C-2 overview

JCB 60C-2 features overview

Choose conventional rear swing for greater stability and strength, or zero tail swings for greater manoeuvrability.

Engine / Driveline and transmission

TOUGH TO BEAT FOR PERFORMANCE.
The new stage v perkins 36kw engine offers up to 5% fuel economy with zero compromise for machine performance and no adblue needed.
THE POWER TO SAVE
4 Power modes allow the operator to choose the right power for use, saving even more fuel.
TOUGH TO BEAT FOR COST OF OWNERSHIP.
Minimum downtime, with a machine health check displayed on the screen before starting. Fuel saving features include one touch idle, programmable auto idling & engine shutdown.

Environment

TOUGH TO BEAT FOR COMFORT.
Increased productivity comes from a comfortable operating environment: a large, quiet cab, thumb-controlled boom swing and auxiliary as well as a hands-free bluetooth radio.

Tyres / Tracks

TOUGH TO BEAT FOR SERVICEABILITY
Unrivalled service access with easy to remove panels, fully opening side & rear hoods and grouped check points.

Dimensions and weight

MODEL	50Z-2	56Z-2	60C-2
Dig depth,"3,327/3,447mm	3,606mm	3,856mm"
Service intervals		500 hours
Transport length,"5,353mm	5,520mm	5,505mm"
Transport height,"2,551mm	2,551mm	2,561mm"
Shipping weight,"4,798kg	5,310kg	5,448kg"
Width over tracks		1	950mm"

Other features

TOUGH TO BEAT FOR EASE OF USE.
7 colour screen with slew selector control, programmable flow for up to 10 attachments and auto auxiliary ventilation allows easy attachment replacement.

Safety

TOUGH TO BEAT FOR SAFETY.
Improved visibility, integrated rear camera, follow me home LED lights, unique 2GO system and 5 years subscription from JCB Livelink contributes to safer work.
