37C HD JCB excavator specs & dimensions (2022 - 2026)

JCB 37C HD is a mini excavator manufactured since 2022, with a weight of 4.052 tons. It features a track width of 300 mm, a transp…

JCB 37C HD is a mini excavator manufactured since 2022, with a weight of 4.052 tons. It features a track width of 300 mm, a transport length of 4.81 meters, a transport width of 1.55 meters, and a transport height of 2.18 meters. The dredging depth is 3.34 meters, and the maximum horizontal reach is 5.02 meters.

Mini Excavators JCB 37C HD
Mini Excavators JCB 37C HD
Mini Excavators JCB 37C HD
Mini Excavators JCB 37C HD

Visit JCB live at

Technical specs - 37C HD JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.052 t
Transport length
4.81 m
Transport width
1.55 m
Transport height
2.18 m
Track width
300 mm
Driver protection
KbR
Max. Reach horizontal
5.02 m
Dredging depth
3.34 m
Engine manuf.
Perkins
Engine type
403J-17
Engine power
18.9 kW
Displacement
1.662 l
Revolutions at max torque
1600 rpm
Max. torque
91.9 Nm
Emission level
EU V / EPA Tier 4 Final

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, tear-out force, model series, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

JCB 37C HD FAQ

When was the JCB 37C HD manufactured?

The JCB 37C HD was first produced in 2022.

How much does the JCB 37C HD mini excavator weigh?

The JCB 37C HD mini excavator weighs 4.05 tons.

What are the transport dimensions of the JCB 37C HD mini excavator?

The JCB 37C HD has a transport length of 4.81 meters, a transport width of 1.55 meters, and a transport height of 2.18 meters.

What is the track width of the JCB 37C HD mini excavator?

The JCB 37C HD mini excavator has a track width of 300 mm.

What are the dredging depth and maximum horizontal reach of the JCB 37C HD mini excavator?

The JCB 37C HD mini excavator has a dredging depth of 3.34 meters and a maximum horizontal reach of 5.02 meters.

What operator safety and support features does the JCB 37C HD have?

The JCB 37C HD is equipped with a cabin that includes ROPS (Roll-Over Protective Structure) for driver protection.

How much is a JCB 37C HD Mini excavator (2022u20132025) worth?

The residual value of the JCB 37C HD depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
