18Z-I JCB excavator specs & dimensions (2021 - 2026)

JCB 18Z-I is a mini excavator manufactured since 2021, with a weight of 1.75 tons. It features a track width of 230 mm and has tra…

JCB 18Z-I is a mini excavator manufactured since 2021, with a weight of 1.75 tons. It features a track width of 230 mm and has transport dimensions of 3.55 m in length, 0.98 m in width, and 2.34 m in height. The machine offers a tear-out force of 18 kN, a dredging depth of 2.43 m, and a maximum horizontal reach of 3.83 m. The bucket width is 0.3 m, and it comes equipped with a blade and rubber tracks.

Mini Excavators JCB 18Z-I
Mini Excavators JCB 18Z-I
Mini Excavators JCB 18Z-I
Mini Excavators JCB 18Z-I
Mini Excavators JCB 18Z-I
Mini Excavators JCB 18Z-I
Mini Excavators JCB 18Z-I
Mini Excavators JCB 18Z-I
Mini Excavators JCB 18Z-I
Mini Excavators JCB 18Z-I
Mini Excavators JCB 18Z-I
Mini Excavators JCB 18Z-I

Visit JCB live at

Technical specs - 18Z-I JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.75 t
Transport length
3.55 m
Transport width
0.98 m
Transport height
2.34 m
Bucket width
0.3 m
Track width
230 mm
Driver protection
FD
Max. Reach horizontal
3.83 m
Dredging depth
2.43 m
Tear-out force
18 kN
Engine manuf.
Perkins
Engine type
403J-07
Engine power
11.7 kW
Displacement
0.762 l
Revolutions at max torque
2000 rpm
Max. torque
45.6 Nm
No. of cylinders
3
Emission level
V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., standard tyres, model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

JCB 18Z-I FAQ

When was the JCB 18Z-I manufactured?

The JCB 18Z-I was first produced in 2021.

How much does the JCB 18Z-I mini excavator weigh?

The JCB 18Z-I mini excavator weighs 1.75 tons.

What are the transport dimensions of the JCB 18Z-I mini excavator?

The JCB 18Z-I has a transport length of 3.55 meters, a transport width of 0.98 meters, and a transport height of 2.34 meters.

What is the track width of the JCB 18Z-I mini excavator?

The JCB 18Z-I mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the JCB 18Z-I mini excavator?

The JCB 18Z-I mini excavator has a dredging depth of 2.43 meters and a maximum horizontal reach of 3.83 meters.

What is the tear-out force of the JCB 18Z-I mini excavator?

The JCB 18Z-I mini excavator has a tear-out force of 18 kN.

What is the bucket width of the JCB 18Z-I mini excavator?

The bucket width of the JCB 18Z-I mini excavator is 0.3 meters.

What operator safety and support features does the JCB 18Z-I have?

The JCB 18Z-I provides operator safety with a canopy for driver protection.

How much is a JCB 18Z-I Mini excavator (2021u20132025) worth?

The residual value of the JCB 18Z-I depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
