Technical specs - XE60GA XCMG

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
6.05 t
Transport length
6.01 m
Transport width
2.04 m
Transport height
2.65 m
Bucket capacity
0.25 m³
Track width
400 mm
Driver protection
Kb
Max. Reach horizontal
6.13 m
Dredging depth
3.83 m
Tear-out force
48.3 kN
Model series
XE
Engine manuf.
Yanmar
Engine type
4TNV94L
Engine power
35.9 kW
Displacement
3.054 l
Revolutions at max torque
2000 rpm
Max. torque
200.8/1400 Nm
No. of cylinders
4

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
