TB219S Takeuchi excavator specs & dimensions (2008 - 2017)

Takeuchi TB219S is a mini excavator manufactured from 2008 to 2017, with a weight of 1.9 tons. It features a track width of 230 mm…

Takeuchi TB219S is a mini excavator manufactured from 2008 to 2017, with a weight of 1.9 tons. It features a track width of 230 mm and a transport width of 0.98 meters. The bucket capacity is 0.05 cubic meters. Special equipment includes a blade, rubber track, and track adjustment.

Mini Excavators Takeuchi TB219S
Mini Excavators Takeuchi TB219S
Mini Excavators Takeuchi TB219S
Mini Excavators Takeuchi TB219S
Mini Excavators Takeuchi TB219S
Mini Excavators Takeuchi TB219S
Mini Excavators Takeuchi TB219S
Mini Excavators Takeuchi TB219S
Mini Excavators Takeuchi TB219S
Mini Excavators Takeuchi TB219S

Technical specs - TB219S Takeuchi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.9 t
Transport width
0.98 m
Bucket capacity
0.05 m³
Track width
230 mm
Driver protection
FD
Model series
TB
Engine manuf.
Yanmar
Engine type
3TNV70
Engine power
11.5 kW
Displacement
0.85 l
Revolutions at max torque
2400 rpm

More technical details, like: transport length, transport height, bucket capacity min., bucket capacity max., bucket width, standard tyres, max. reach horizontal, dredging depth, tear-out force, dimension lxwxh, max. torque, no. of cylinders...

More technical details, like: transport length, transport height, bucket capacity min., bucket capacity max., bucket width, standard tyres, max. reach horizontal, dredging depth, tear-out force, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Takeuchi TB219S FAQ

When was the Takeuchi TB219S manufactured?

The Takeuchi TB219S was manufactured from 2008 to 2017.

How much does the Takeuchi TB219S weigh?

The Takeuchi TB219S weighs 1.9 tons.

What is the transport width of the Takeuchi TB219S mini excavator?

The Takeuchi TB219S has a transport width of 0.98 meters.

What is the track width of the Takeuchi TB219S mini excavator?

The Takeuchi TB219S mini excavator has a track width of 230 mm.

What is the bucket capacity of the Takeuchi TB219S mini excavator?

The bucket capacity of the Takeuchi TB219S mini excavator is 0.05 cubic meters.

What operator safety and support features does the Takeuchi TB219S have?

The Takeuchi TB219S is equipped with a canopy for driver protection.

How much is a Takeuchi TB219S Mini excavator (2008u20132017) worth?

The residual value of the Takeuchi TB219S depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
