NR 5.5-1 Neumeier excavator specs & dimensions (2011 - 2020)

Neumeier NR 5.5-1 is a mini excavator manufactured since 2011. It has a weight of 5.71 tons and a track width of 400 mm. The trans…

Neumeier NR 5.5-1 is a mini excavator manufactured since 2011. It has a weight of 5.71 tons and a track width of 400 mm. The transport dimensions are 6.05 meters in length, 1.9 meters in width, and 2.59 meters in height. The machine features a tear-out force of 42 kN, a dredging depth of 3.835 meters, and a maximum horizontal reach of 6.335 meters. The bucket capacity is 0.22 cubic meters. Special equipment includes air conditioning, a blade, and rubber tracks.

NR 5.5-1

Years of manufacture: 2011—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - NR 5.5-1 Neumeier

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.71 t

Transport length: 6.05 m

Transport width: 1.9 m

Transport height: 2.59 m

Bucket capacity: 0.22 m³

Track width: 400 mm

Driver protection: Kb

Max. Reach horizontal: 6.335 m

Dredging depth: 3.835 m

Tear-out force: 42 kN

Model series: NR

Engine manuf.: Yanmar

Engine type: XSNVA

Engine power: 36.9 kW

Revolutions at max torque: 2200 rpm

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

NR 5.5-1 Neumeier Specification for Europe (DE)

Neumeier NR 5.5-1 FAQ

When was the Neumeier NR 5.5-1 manufactured?

The Neumeier NR 5.5-1 was first produced in 2011.

How much does the Neumeier NR 5.5-1 weigh?

The Neumeier NR 5.5-1 weighs 5.71 tons.

What are the transport dimensions of the Neumeier NR 5.5-1 mini excavator?

The Neumeier NR 5.5-1 has a transport length of 6.05 meters, a transport width of 1.9 meters, and a transport height of 2.59 meters.

What is the track width of the Neumeier NR 5.5-1 mini excavator?

The Neumeier NR 5.5-1 mini excavator has a track width of 400 mm.

What are the excavation performance specifications of the Neumeier NR 5.5-1 mini excavator?

The Neumeier NR 5.5-1 mini excavator has a dredging depth of 3.835 meters and a maximum horizontal reach of 6.335 meters.

What is the tear-out force of the Neumeier NR 5.5-1 mini excavator?

The Neumeier NR 5.5-1 mini excavator has a tear-out force of 42 kN.

What is the bucket capacity of the Neumeier NR 5.5-1 mini excavator?

The Neumeier NR 5.5-1 mini excavator has a bucket capacity of 0.22 cubic meters.

What operator safety and support features does the Neumeier NR 5.5-1 have?

The Neumeier NR 5.5-1 provides operator safety with a driver protection cabin.
