6MCR Mecalac excavator specs & dimensions (2021 - 2026)

Mecalac 6MCR is a mini excavator manufactured since 2021, with a weight of 5.7 tons. It features a track width of 400 mm, a transp…

Mecalac 6MCR is a mini excavator manufactured since 2021, with a weight of 5.7 tons. It features a track width of 400 mm, a transport length of 2.83 meters, a transport width of 2.03 meters, and a transport height of 2.751 meters. The machine has a tear-out force of 25 kN and a maximum horizontal reach of 6.22 meters. It comes with a bucket capacity of 0.185 cubic meters and includes special equipment such as a blade and a hydraulic quick hitch.

6MCR

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 6MCR Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.7 t

Transport length: 2.83 m

Transport width: 2.03 m

Transport height: 2.75 m

Bucket capacity: 0.185 m³

Bucket width: 0.6 m

Track width: 400 mm

Max. Reach horizontal: 6.22 m

Dredging depth: 3.3 m

Tear-out force: 25 kN

Model series: MCR

Engine manuf.: Deutz

Engine type: TCD2.9 L4

Engine power: 55.4 kW

Displacement: 2.9 l

Revolutions at max torque: 2300 rpm

Max. torque: 300/1600 Nm

No. of cylinders: 4

Cylinder bore x stroke: 92x110 mm

Emission level: EU V

More technical details, like: bucket capacity min., bucket capacity max., standard tyres, driver protection, dimension lxwxh are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: No
Blade: Yes
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Mecalac 6MCR FAQ

When was the Mecalac 6MCR manufactured?

The Mecalac 6MCR was first produced in 2021.

How much does the Mecalac 6MCR weigh?

The Mecalac 6MCR weighs 5.7 tons.

What are the transport dimensions of the Mecalac 6MCR mini excavator?

The Mecalac 6MCR has a transport length of 2.83 meters, a transport width of 2.03 meters, and a transport height of 2.75 meters.

What is the track width of the Mecalac 6MCR mini excavator's undercarriage?

The Mecalac 6MCR mini excavator has a track width of 400 mm.

What is the excavation performance of the Mecalac 6MCR mini excavator?

The Mecalac 6MCR mini excavator has a dredging depth of 3.3 meters and a maximum horizontal reach of 6.22 meters.

What is the tear-out force of the Mecalac 6MCR mini excavator?

The Mecalac 6MCR mini excavator has a tear-out force of 25 kN.

What are the specifications of the primary work tool bucket on the Mecalac 6MCR mini excavator?

The primary work tool bucket of the Mecalac 6MCR has a capacity of 0.185 cubic meters and a width of 0.6 meters.
