SK 17 SR 6E Kobelco excavator specs & dimensions (2022 - 2026)

Kobelco SK 17 SR 6E is a mini excavator manufactured since 2022, with a weight of 1.61 t. It features a track width of 230 mm, a t…

Kobelco SK 17 SR 6E is a mini excavator manufactured since 2022, with a weight of 1.61 t. It features a track width of 230 mm, a transport length of 3.46 m, a transport width of 1.28 m, and a transport height of 2.32 m. The machine has a tear-out force of 18.3 kN, a dredging depth of 2.21 m, and a maximum horizontal reach of 1.54 m. The bucket capacity is 0.04 m³, and it comes equipped with a blade and rubber tracks.

Mini Excavators Kobelco SK 17 SR 6E

Visit Kobelco live at

Technical specs - SK 17 SR 6E Kobelco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.61 t
Transport length
3.46 m
Transport width
1.28 m
Transport height
2.32 m
Bucket capacity
0.04 m³
Track width
230 mm
Driver protection
FD
Max. Reach horizontal
1.54 m
Dredging depth
2.21 m
Tear-out force
18.3 kN
Model series
SK
Engine manuf.
Yanmar
Engine type
3TNV74F-SPBV
Engine power
10.8 kW
Displacement
1 l
Revolutions at max torque
2400 rpm
Max. torque
49.2 Nm
No. of cylinders
3
Emission level
Tier 4

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kobelco SK 17 SR 6E FAQ

When was the Kobelco SK 17 SR 6E manufactured?

The Kobelco SK 17 SR 6E was first produced in 2022.

How much does the Kobelco SK 17 SR 6E weigh?

The Kobelco SK 17 SR 6E weighs 1.61 tons.

What are the transport dimensions of the Kobelco SK 17 SR 6E mini excavator?

The Kobelco SK 17 SR 6E has a transport length of 3.46 meters, a transport width of 1.28 meters, and a transport height of 2.32 meters.

What is the track width of the Kobelco SK 17 SR 6E mini excavator?

The Kobelco SK 17 SR 6E has a track width of 230 mm.

What are the excavation performance specifications of the Kobelco SK 17 SR 6E mini excavator?

The Kobelco SK 17 SR 6E has a dredging depth of 2.21 meters and a maximum horizontal reach of 1.54 meters.

What is the tear-out force of the Kobelco SK 17 SR 6E mini excavator?

The Kobelco SK 17 SR 6E mini excavator has a tear-out force of 18.3 kN.

What is the bucket capacity of the Kobelco SK 17 SR 6E mini excavator?

The Kobelco SK 17 SR 6E mini excavator has a bucket capacity of 0.04 cubic meters.

What operator safety feature does the Kobelco SK 17 SR 6E have?

The Kobelco SK 17 SR 6E is equipped with a canopy for driver protection.

How much is a Kobelco SK 17 SR 6E Mini excavator (2022u20132025) worth?

The residual value of the Kobelco SK 17 SR 6E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
