55N4 Kato excavator specs & dimensions (2017 - 2023)

Kato 55N4 is a Mini Excavator manufactured since 2017, with a weight of 5.35 t. It features a track width of 400 mm, a transport l…

Kato 55N4 is a Mini Excavator manufactured since 2017, with a weight of 5.35 t. It features a track width of 400 mm, a transport length of 5.86 m, a transport width of 2 m, and a transport height of 2.57 m. The machine has a tear-out force of 36.3 kN, a dredging depth of 3.85 m, and a maximum horizontal reach of 5.98 m. The bucket width is 0.685 m, with a bucket capacity of 0.18 m³. It is equipped with a blade as special equipment.

Mini Excavators Kato 55N4

Technical specs - 55N4 Kato

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5.35 t
Transport length
5.86 m
Transport width
2 m
Transport height
2.57 m
Bucket capacity
0.18 m³
Bucket width
0.685 m
Track width
400 mm
Driver protection
FD
Max. Reach horizontal
5.98 m
Dredging depth
3.85 m
Tear-out force
36.3 kN
Model series
N
Engine manuf.
Yanmar
Engine type
4TNV98C
Engine power
47.6 kW
Emission level
Tier 4

More technical details, like: bucket capacity min., bucket capacity max., standard tyres, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kato 55N4 FAQ

When was the Kato 55N4 manufactured?

The Kato 55N4 was manufactured from 2017 to 2023.

How much does the Kato 55N4 mini excavator weigh?

The Kato 55N4 mini excavator weighs 5.35 tons.

What are the transport dimensions of the Kato 55N4 mini excavator?

The Kato 55N4 has a transport length of 5.86 meters, a transport width of 2 meters, and a transport height of 2.57 meters.

What is the track width of the Kato 55N4 mini excavator?

The Kato 55N4 mini excavator has a track width of 400 mm.

What are the excavation performance specifications of the Kato 55N4 mini excavator?

The Kato 55N4 mini excavator has a dredging depth of 3.85 meters and a maximum horizontal reach of 5.98 meters.

What is the tear-out force of the Kato 55N4 mini excavator?

The Kato 55N4 mini excavator has a tear-out force of 36.3 kN.

What are the specifications of the primary work tool bucket on the Kato 55N4 mini excavator?

The primary work tool bucket of the Kato 55N4 mini excavator has a capacity of 0.18 cubic meters and a width of 0.685 meters.

What operator safety features does the Kato 55N4 have?

The Kato 55N4 has a canopy for driver protection.
