8018 CTS JCB excavator specs & dimensions (2005 - 2017)

JCB 8018 CTS is a Mini Excavator manufactured from 2005 to 2017, with a weight of 1.82 tons. It features a track width of 230 mm, …

JCB 8018 CTS is a Mini Excavator manufactured from 2005 to 2017, with a weight of 1.82 tons. It features a track width of 230 mm, a transport length of 3.52 meters, a transport width of 0.98 meters, and a transport height of 2.34 meters. The machine has a tear-out force of 16.2 kN, a dredging depth of 2.74 meters, and a maximum horizontal reach of 4.07 meters. The bucket width is 0.3 meters with a capacity of 0.04 cubic meters. Special equipment includes a blade, rubber track, and track adjustment.

Visit JCB live at

8018 CTS

Years of manufacture: 2005—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - 8018 CTS JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.82 t

Transport length: 3.52 m

Transport width: 0.98 m

Transport height: 2.34 m

Bucket capacity: 0.04 m³

Bucket width: 0.3 m

Track width: 230 mm

Driver protection: Kb

Max. Reach horizontal: 4.07 m

Dredging depth: 2.74 m

Tear-out force: 16.2 kN

Engine manuf.: Perkins

Engine type: 403D-11

Engine power: 14.2 kW

Displacement: 1.131 l

Revolutions at max torque: 1600 rpm

Max. torque: 64.2 Nm

Emission level: Stufe III A

More technical details, like: bucket capacity min., bucket capacity max., standard tyres, model series, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: Yes
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

JCB 8018 CTS FAQ

When was the JCB 8018 CTS manufactured?

The JCB 8018 CTS was manufactured from 2005 to 2017.

How much does the JCB 8018 CTS weigh?

The JCB 8018 CTS weighs 1.82 tons.

What are the transport dimensions of the JCB 8018 CTS mini excavator?

The JCB 8018 CTS has a transport length of 3.52 meters, a transport width of 0.98 meters, and a transport height of 2.34 meters.

What is the track width of the JCB 8018 CTS mini excavator?

The JCB 8018 CTS mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the JCB 8018 CTS mini excavator?

The JCB 8018 CTS mini excavator has a dredging depth of 2.74 meters and a maximum horizontal reach of 4.07 meters.

What is the tear-out force of the JCB 8018 CTS mini excavator?

The JCB 8018 CTS mini excavator has a tear-out force of 16.2 kN.

What are the specifications of the bucket on the JCB 8018 CTS mini excavator?

The bucket of the JCB 8018 CTS has a capacity of 0.04 cubic meters and a width of 0.3 meters.

What operator safety and support features does the JCB 8018 CTS have?

The JCB 8018 CTS provides operator safety through a protective cabin.

How much is a JCB 8018 CTS Mini excavator (2005u20132017) worth?

The residual value of the JCB 8018 CTS depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

JCB 8018 CTS overview

Dimensions and weight

Machine Model	8018 CTS
	ft-in (mm)
A Sprocket Idler Centers	3-8 (1127)
B Undercarriage Overall Length	5-10 (1484)
C Kingpost Clearance	1-3 (376)
D Tailswing Radius	3-41 ⁄2 (1028)
E Overall Width of Superstructure	3-21 ⁄2 (980)
F Height Over Cab	7-7 (2318)
G Ground Clearance	0-6 (158)
H Track Gauge	2-51 ⁄2 to 3-73 ⁄4 (750 to 1110)

Machine Model	8018 CTS
	ft-in (mm)
I Width Over Tracks (retracted)	3-21 ⁄2 (980)
Width Over Tracks (extended)	4-5 (1340)
J Transport Length – Standard Dipper	11-21 ⁄2 (3418)
J Transport Length – Long Dipper	11-0 (3352)
J Transport Length – Gravemaster Dipper	10-63 ⁄4 (3219)
K Transport Height with FOGS Guard	7-7 (2318)
K Transport Height without FOGS Guard	7-61 ⁄2 (2304)
L Track Height	1-2 (366)

MACHINE WEIGHT
Machine Model		8018 CTS
Operating Weight*	lb (kg)	3664 (1662)
Transport Weight	lb (kg)	3499 (1587)
With Canopy	lb (kg)	-176 (-80)
With FOGS Guard	lb (kg)	+55 (+25)
With Long Dipper	lb (kg)	+41 ⁄2 (+2)
With Gravemaster Dipper	lb (kg)	+151 ⁄2 (+7)

	External	Internal
Cab/Canopy Height with FOGS Guard	ft-in (mm)	7-7 (2318)	7-5 (2269)
Cab/Canopy Height no FOGS Guard	ft-in (mm)	7-61 ⁄2 (2304)	7-5 (2269)
Cab/Canopy Length	ft-in (mm)	3-11 (1171)	3-6 (1073)
Cab/Canopy Width	ft-in (mm)	3-2 (974)		2-11 (888)
Distance from Seat Base to Roof	ft-in (mm)		4-0	(1223)
Door Aperture Width	ft-in (mm)	2-01 ⁄2	(624)

Machine Model		8018 CTS
		Standard
Max Height (above ground)	ft-in (mm)	0-7 (178)
Dig Depth (below ground)	ft-in (mm)	0-111 ⁄2 (292)
Approach Angle	degrees	26.5
Width	ft-in (mm)	3-3 (1000)
Width (extended)	ft-in (mm)	4-61 ⁄4 (1380)
Height	ft-in (mm)	0-9 (225)
Reach in Front of Tracks	ft-in (mm)	0-8 (202)

Machine Model		8018 CTS	8018 CTS	8018 CTS
Dipper Length	ft-in (mm)	3-10 (1161)	4-2 (1261)	4-11 (1500)
A Max Digging Reach	ft-in (mm)	12-11 (3933)	13-21 ⁄2 (4028)	13-111 ⁄2 (4254)
B Max Digging Reach on Ground	ft-in (mm)	12-8 (3865)	12-11 (3949)	13-83 ⁄4 (4184)
C Max Digging Depth – Dozer Up	ft-in (mm)	7-0 (2142)	7-4 (2242)	8-11 ⁄2 (2477)
Max Digging Depth – Dozer Down	ft-in (mm)	8-1 (2470)	8-5 (2570)	9-21 ⁄2 (2805)
D Max Digging Height	ft-in (mm)	11-4 (3460)	11-61 ⁄2 (3519)	12-0 (3660)
E Max Dump Height	ft-in (mm)	8-5 (2568)	8-7 (2626)	9-03 ⁄4 (2765)
F Max Height to Dipper Nose Pivot Pin	ft-in (mm)	9-9 (2973)	9-11 (3032)	10-43 ⁄4 (3172)
G Max Vertical Wallcut Depth	ft-in (mm)	5-9 (1750)	6-01 ⁄2 (1845)	6-10 (2082)
Min Front Swing Radius (no offset)	ft-in (mm)	5-71 ⁄2 (1715)	5-81 ⁄2 (1739)	5-101 ⁄2 (1791)
Min Front Swing Radius (fully offset)	ft-in (mm)	5-0 (1529)	5-1 (1552)	5-2 (1574)
Boom Swing Left	degrees	55	55	55
Boom Swing Right	degrees	75	75	75
Bucket Rotation	degrees	198	198	198
Dipper Rotation	degrees	112	112	112
Bucket Tearout	lbf (kN)	3642 (16.2)	3642 (16.2)	–
Dipper Tearout	lbf (kN)	2068 (9.2)	1866 (8.3)	–
Slew Speed	rpm	10	10	10

Tables

SERVICE CAPACITIES
Machine Model		8018 CTS
Fuel Tank	gal (l)	6.2 (23.5)
Engine Coolant	gal (l)	1.32 (5)
Engine Oil	gal (l)	1.05 (4)
Hydraulic System	gal (l)	7.4 (28)
Hydraulic Tank	gal (l)	6.6 (25)

	Standard Gear Pump	Optional Variable Pump
Pump		Triple Section Gear	1 Variable (2 Ports) / 1 Gear
Nominal Output	lpm	43.6 (15.7 x 15.7 x 12.2)	46.9 (17.1 x 17.1 x 12.7)
Nominal Output	gal/min	11.5 (4.15 x 4.15 x 3.2)	12.4 (4.5 x 4.5 x 3.4)
Excavator/Track Main Relief	psi (bar)	3336 (230)	3336 (230)
Slew Main Relief	psi (bar)	2321 (160)	2321 (160)
Auxiliary Hydraulic Flow	gal (l)	8.3 (31.3)	9 (34.2)
Hydraulic Motors		Piston	Piston

UNDERCARRIAGE
Machine Model		8018 CTS
No of Bottom Rollers		3
Track Width	in (mm)	9 (230)
Ground Bearing Pressure	lb/in2 (kg/cm2 )	4.55 (0.32)
Ground Clearance	in (mm)	6 (158)
Track Tensioning		Grease
Travel Speed – Low	mph (kph)	1.24 (2)
Travel Speed – High	mph (kph)	2.36 (3.8)
Tractive Effort	lbf (kN)	2540 (11.3)

Machine Model	8018 CTS
Model	403D-11
Fuel		Diesel
Cooling		Water Cooled
Gross Power	hp (kW) @ 2200 rpm	19.7 (14.7)
Net Power	hp (kW) @ 2200 rpm	19 (14.2)
Gross Torque	lbf ft (Nm) @ 1900 rpm	49.3 (66.8)
Net Torque	lbf ft (Nm) @ 1900 rpm	47.4 (64.2)
Displacement	cid (cc)	69 (1131)
Gradeability	degrees	35
Starter Motor	hp (kW)	1.5 (1.1)
Battery	V (A)	12 (60)
Alternator	A	40
Emission Certification		Interim Tier IV

Height	Dozer up	Dozer down	Retracted	Extended	Dozer up	Dozer down	Retracted	Extended	Dozer up	Dozer down	Retracted	Extended	Dozer up	Dozer down	Retracted	Extended	Dozer up	Dozer down	Retracted	Extended	Distance
ft-in (mm)	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	lb	ft-in (mm)
4-11 (1500)													441	448	481	478	381	511	317	518	11-3 (3430)
3-3 (1000)					761	805	761	763	672	694	672	675	571	595	553	556	443	545	282	556	11-53⁄4 (3500)
1-8 (500)					1058	1250	703	1124	866	1025	582	917	608	739	465	683	381	597	276	437	11-53⁄4 (3500)
Ground Level	1052	1676	847	1407	882	1422	697	1155	728	1105	531	1054	575	833	432	805	362	602	304	476	11-01⁄4 (3360)
1-8 (–500) –	1023	2072	829	1202	871	1528	692	1107	677	1199	516	895	496	829	401	679	381	648	335	514	10-31⁄2(3140)
3-3 (–1000) –	966	1594	822	1230	732	1362	626	1038	635	1228	520	847	489	866	395	657	414	714	333	562	9-6 (2900)
