16C-I JCB excavator specs & dimensions (2021 - 2022)

JCB 16C-I is a mini excavator manufactured from 2021 to 2022, weighing 1.63 tons. It features a track width of 230 mm, a transport…

JCB 16C-I is a mini excavator manufactured from 2021 to 2022, weighing 1.63 tons. It features a track width of 230 mm, a transport length of 3.86 meters, a transport width of 0.99 meters, and a transport height of 2.32 meters. The machine has a dredging depth of 2.57 meters and a maximum horizontal reach of 4 meters. It is equipped with a blade.

Mini Excavators JCB 16C-I
Mini Excavators JCB 16C-I
Mini Excavators JCB 16C-I
Mini Excavators JCB 16C-I
Mini Excavators JCB 16C-I
Mini Excavators JCB 16C-I
Mini Excavators JCB 16C-I
Mini Excavators JCB 16C-I

Visit JCB live at

Technical specs - 16C-I JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.63 t
Transport length
3.86 m
Transport width
0.99 m
Transport height
2.32 m
Track width
230 mm
Driver protection
FD
Max. Reach horizontal
4 m
Dredging depth
2.57 m
Engine manuf.
Perkins
Engine type
403J-07
Engine power
11.7 kW
Displacement
0.762 l
Revolutions at max torque
2000 rpm
Max. torque
45.6 Nm
No. of cylinders
3
Emission level
V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, tear-out force, model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

JCB 16C-I FAQ

When was the JCB 16C-I manufactured?

The JCB 16C-I was manufactured from 2021 to 2022.

How much does the JCB 16C-I mini excavator weigh?

The JCB 16C-I mini excavator weighs 1.63 tons.

What are the transport dimensions of the JCB 16C-I mini excavator?

The JCB 16C-I mini excavator has a transport length of 3.86 meters, a transport width of 0.99 meters, and a transport height of 2.32 meters.

What is the track width of the JCB 16C-I mini excavator?

The JCB 16C-I mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the JCB 16C-I mini excavator?

The JCB 16C-I mini excavator has a dredging depth of 2.57 meters and a maximum horizontal reach of 4 meters.

What operator safety and support features does the JCB 16C-I have?

The JCB 16C-I provides operator safety with a canopy for driver protection.

How much is a JCB 16C-I Mini excavator (2021u20132022) worth?

The residual value of the JCB 16C-I depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
