Dimensions and weight
| DIMENSIONS | |||
| Maximum width | mm | 1.900 | |
| Total height | mm | 2.570 | |
| Rear rotation radius | mm | 950 | |
| Digging arm length std (optional) | mm | 1.500 (1.750) | |
| Tracks width | mm | 400 | |
| Rollers number (for each side) | n° | 5/1 | |
| FILLINGS | |||
| Fuel tank | lt | 75 | |
| Hydraulic oil tank | lt | 65 | |
| Hydraulic circuit capacity | lt | 85 | |
| Cooling system capacity | lt | 11 | |
| Engine oil | lt | 9 | 5" |
| HYDRAULIC SYSTEM | |||
| Circuit Type | Load Sensing closed center system with “Flow Sharing” control valve | ||
| Pump type | 1 LS hydraulic variable pump with electronic control + 1 gear pump | ||
| Pump displacement | cc | 65 + 14 | 5" |
| Pump capacity | lt/min | 129 + 28 | 8" |
| Max. circuit calibration pressure | bar | 280 | |
| Auxiliary systems (max pressure): AUX 1 single or double effect with priority AUX 2 double effect (optional) | lt/min (bar) | 70 (200) 40/30 (280) | |
| PERFORMANCES | |||
| Max. digging depth with standard arm (optional arm) | mm | 3.330 (3.580) | |
| Max. dumping height with standard arm (optional arm) | mm | 3.920 (4.080) | |
| Bucket breaking force (standard arm) ISO 6015 | daN | 4.300 | |
| Arm breaking force (standard arm) ISO 6015 | daN | 2.350 | |
| Traction force | daN | 5.420 | |
| Ground bearing pressure with rubber tracks and cabine | kg/cm2 | 0 | 28" |
