DX27Z-7 Develon excavator specs & dimensions (2023 - 2026)

Weight: 2.798t – Transport length: 4.191m – Transport width: 1.55m – Transport height: 2.448m – Bucket capacity: 0.08m³ – Bucket c…

Weight: 2.798t – Transport length: 4.191m – Transport width: 1.55m – Transport height: 2.448m – Bucket capacity: 0.08m³ – Bucket capacity min.: 0.06m³

Check out detailed specifications, information and technical data for Develon DX27Z-7 excavator manufactured between 2023 - 2026. Get more in-depth insight with Develon DX27Z-7 digger specifications. See information, like: Weight: 2.798t – Transport length: 4.191m – Transport width: 1.55m – Transport height: 2.448m – Bucket capacity: 0.08m³ – Bucket capacity min.: 0.06m³ and more.

Mini Excavators Develon DX27Z-7

Visit Develon live at

Technical specs - DX27Z-7 Develon

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.798 t
Transport length
4.191 m
Transport width
1.55 m
Transport height
2.448 m
Bucket capacity
0.08 m³
Bucket capacity min.
0.06 m³
Bucket capacity max.
0.08 m³
Bucket width
0.398 m
Track width
300 mm
Driver protection
KbR
Max. Reach horizontal
4.845 m
Dredging depth
2.845 m
Tear-out force
14.2 kN
Model series
DX
Engine manuf.
Develon
Engine type
DN17
Engine power
18.4 kW
Dimension lxwxh
615x495x628 mm
Displacement
1.647 l
Revolutions at max torque
2400 rpm
Max. torque
97/1600 Nm
No. of cylinders
3
Cylinder bore x stroke
87x92,4 mm
Emission level
Stage V

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Develon DX27Z-7 FAQ

When was the Develon DX27Z-7 manufactured?

The Develon DX27Z-7 was first produced in 2023.

How much does the Develon DX27Z-7 mini excavator weigh?

The Develon DX27Z-7 mini excavator weighs 2.798 tons.

What are the transport dimensions of the Develon DX27Z-7 mini excavator?

The Develon DX27Z-7 has a transport length of 4.191 meters, a transport width of 1.55 meters, and a transport height of 2.448 meters.

What is the track width of the Develon DX27Z-7 mini excavator?

The Develon DX27Z-7 mini excavator has a track width of 300 mm.

What are the excavation performance specifications of the Develon DX27Z-7 mini excavator?

The Develon DX27Z-7 has a dredging depth of 2.845 meters and a maximum horizontal reach of 4.845 meters.

What is the tear-out force of the Develon DX27Z-7 mini excavator?

The Develon DX27Z-7 mini excavator has a tear-out force of 14.2 kN.

What are the specifications of the primary work tool bucket on the Develon DX27Z-7 mini excavator?

The Develon DX27Z-7 mini excavator's primary work tool bucket has a capacity ranging from 0.06 to 0.08 cubic meters, with a standard capacity of 0.08 cubic meters and a width of 0.398 meters.

What operator safety and support features does the Develon DX27Z-7 have?

The Develon DX27Z-7 is equipped with a cabin that includes ROPS (Roll-Over Protective Structure) for driver protection.

How much is a Develon DX27Z-7 Mini excavator (2023u20132025) worth?

The residual value of the Develon DX27Z-7 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
