E50z Bobcat excavator specs & dimensions (2021 - 2026)

Bobcat E50z is a mini excavator manufactured since 2021, with a weight of 5 tons. It features a track width of 350 mm, a transport…

Bobcat E50z is a mini excavator manufactured since 2021, with a weight of 5 tons. It features a track width of 350 mm, a transport length of 5.3 meters, a transport width of 1.9 meters, and a transport height of 2.5 meters. The machine has a tear-out force of 37 kN, a dredging depth of 3.5 meters, and a maximum horizontal reach of 5.9 meters.

Visit Bobcat live at

E50z

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - E50z Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5 t

Transport length: 5.3 m

Transport width: 1.9 m

Transport height: 2.5 m

Track width: 350 mm

Max. Reach horizontal: 5.9 m

Dredging depth: 3.5 m

Tear-out force: 37 kN

Model series: E

Engine manuf.: Bobcat

Engine type: 1.8L

Engine power: 31.3 kW

Displacement: 1.8 l

Max. torque: 155 Nm

No. of cylinders: 3

Emission level: EU Stage V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, driver protection, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: No
Blade: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Bobcat E50z FAQ

When was the Bobcat E50z manufactured?

The Bobcat E50z was first produced in 2021.

How much does the Bobcat E50z weigh?

The Bobcat E50z weighs 5 tons.

What are the transport dimensions of the Bobcat E50z mini excavator?

The Bobcat E50z has a transport length of 5.3 meters, a transport width of 1.9 meters, and a transport height of 2.5 meters.

What is the track width of the Bobcat E50z mini excavator?

The Bobcat E50z mini excavator has a track width of 350 mm.

What are the excavation performance specifications of the Bobcat E50z mini excavator?

The Bobcat E50z mini excavator has a dredging depth of 3.5 meters and a maximum horizontal reach of 5.9 meters.

What is the tear-out force of the Bobcat E50z mini excavator?

The Bobcat E50z mini excavator has a tear-out force of 37 kN.

How much is a Bobcat E50z Mini excavator (2021u20132025) worth?

The residual value of the Bobcat E50z depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
