ViO82 Yanmar excavator specs & Dimensions (2023 - 2026)

Weight: 8.2t – Transport length: 6.92m – Transport width: 2.27m – Transport height: 2.785m – Track width: 450mm – Max. Reach horiz…

Weight: 8.2t – Transport length: 6.92m – Transport width: 2.27m – Transport height: 2.785m – Track width: 450mm – Max. Reach horizontal: 6.82m

Check out detailed specifications, information and technical data for Yanmar ViO82 excavator manufactured between 2023 - 2026. Get more in-depth insight with Yanmar ViO82 digger specifications. See information, like: Weight: 8.2t – Transport length: 6.92m – Transport width: 2.27m – Transport height: 2.785m – Track width: 450mm – Max. Reach horizontal: 6.82m and more.

Crawler Excavators Yanmar ViO82
Crawler Excavators Yanmar ViO82
Crawler Excavators Yanmar ViO82
Crawler Excavators Yanmar ViO82
Crawler Excavators Yanmar ViO82
Crawler Excavators Yanmar ViO82
Crawler Excavators Yanmar ViO82
Crawler Excavators Yanmar ViO82
Crawler Excavators Yanmar ViO82
Crawler Excavators Yanmar ViO82

Technical specs - ViO82 Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.2 t
Transport length
6.92 m
Transport width
2.27 m
Transport height
2.785 m
Track width
450 mm
Max. Reach horizontal
6.82 m
Dredging depth
4.44 m
Tear-out force
63.5 kN
Model series
ViO
Engine manuf.
Yanmar
Engine type
4TNV98C-WBV
Engine power
39.3 kW
Displacement
3.318 l
Revolutions at max torque
1900 rpm
Max. torque
241 Nm
No. of cylinders
4

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Yanmar ViO82 FAQ

When was the Yanmar ViO82 manufactured?

The Yanmar ViO82 was first produced in 2024.

How much does the Yanmar ViO82 weigh?

The Yanmar ViO82 weighs 8.2 tons.

What are the transport dimensions of the Yanmar ViO82 crawler excavator?

The Yanmar ViO82 has a transport length of 6.92 meters, a transport width of 2.27 meters, and a transport height of 2.785 meters.

What is the track width of the Yanmar ViO82's undercarriage?

The Yanmar ViO82 has a track width of 450 mm on its undercarriage.

What are the excavation performance specifications of the Yanmar ViO82?

The Yanmar ViO82 has a dredging depth of 4.44 meters and a maximum horizontal reach of 6.82 meters.

What is the tear-out force of the Yanmar ViO82?

The Yanmar ViO82 has a tear-out force of 63.5 kN. No power rating data is provided in the source.

How much is a Yanmar ViO82 Crawler excavator (2024u20132025) worth?

The residual value of the Yanmar ViO82 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
