85D John Deere Construction excavator specs & Dimensions (2010 - 2021)

John Deere Construction 85D is a crawler excavator manufactured from 2010 to 2021. It has a weight of 8.53 tons, a track width of …

John Deere Construction 85D is a crawler excavator manufactured from 2010 to 2021. It has a weight of 8.53 tons, a track width of 600 mm, a transport length of 6.7 meters, a transport width of 2.47 meters, and a transport height of 2.26 meters. The machine features a tear-out force of 55 kN, a dredging depth of 3.97 meters, and a maximum horizontal reach of 7.05 meters. Special equipment includes a blade and track adjustment.

Crawler Excavators John Deere Construction 85D

Technical specs - 85D John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.53 t
Transport length
6.7 m
Transport width
2.47 m
Transport height
2.26 m
Track width
600 mm
Max. Reach horizontal
7.05 m
Dredging depth
3.97 m
Tear-out force
55 kN
Model series
D
Engine manuf.
Isuzu
Engine type
4LE2X
Engine power
40 kW
Displacement
2.2 l
No. of cylinders
4
Emission level
Stage III

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
Yes
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

John Deere Construction 85D FAQ

When was the John Deere Construction 85D manufactured?

The John Deere Construction 85D was manufactured from 2010 to 2021.

How much does the John Deere Construction 85D weigh?

The John Deere Construction 85D weighs 8.53 tons.

What are the transport dimensions of the John Deere Construction 85D?

The John Deere Construction 85D has a transport length of 6.7 meters, a transport width of 2.47 meters, and a transport height of 2.26 meters.

What is the track width of the John Deere Construction 85D's undercarriage?

The John Deere Construction 85D has a track width of 600 mm.

What is the excavation performance of the John Deere Construction 85D?

The John Deere Construction 85D has a dredging depth of 3.97 meters and a maximum horizontal reach of 7.05 meters.

What is the tear-out force of the John Deere Construction 85D?

The John Deere Construction 85D has a tear-out force of 55 kN.
