60G John Deere Construction excavator specs & Dimensions (2013 - 2026)

John Deere Construction 60G is a Crawler Excavator manufactured since 2013. It has a weight of 6.14 tons and a track width of 400 …

John Deere Construction 60G is a Crawler Excavator manufactured since 2013. It has a weight of 6.14 tons and a track width of 400 mm. The transport dimensions are 5.76 meters in length, 2 meters in width, and 2.54 meters in height. The dredging depth is 3.77 meters, and the maximum horizontal reach is also 3.77 meters. This model includes special equipment such as a blade.

Crawler Excavators John Deere Construction 60G

Technical specs - 60G John Deere Construction

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
6.14 t
Transport length
5.76 m
Transport width
2 m
Transport height
2.54 m
Track width
400 mm
Max. Reach horizontal
3.77 m
Dredging depth
3.77 m
Model series
G
Engine manuf.
Yanmar
Engine type
4TNV98C-WHB
Engine power
40 kW
Displacement
3.3 l
No. of cylinders
3
Emission level
EPA Final Tier 4/EU Stage IV

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, tear-out force, bucket width, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

John Deere Construction 60G FAQ

When was the John Deere Construction 60G manufactured?

The John Deere Construction 60G was first produced in 2013.

How much does the John Deere Construction 60G weigh?

The John Deere Construction 60G weighs 6.14 tons.

What are the transport dimensions of the John Deere Construction 60G?

The John Deere Construction 60G has a transport length of 5.76 meters, a transport width of 2 meters, and a transport height of 2.54 meters.

What is the track width of the John Deere Construction 60G's undercarriage?

The John Deere Construction 60G has a track width of 400 mm.

What is the excavation performance of the John Deere Construction 60G?

The John Deere Construction 60G has a dredging depth of 3.77 meters and a maximum horizontal reach of 3.77 meters.
