    Yanmar VIO 80 U excavator specs (2011 - 2016)

    7,00/10 Rate this machine now!

    Yanmar is the manufacturer of the crawler excavator model VIO 80 U. Find and download detailed specs and data sheets for this mach... Read more

    Yanmar is the manufacturer of the crawler excavator model VIO 80 U. Find and download detailed specs and data sheets for this machine here.

    Equipped with a powerful Yanmar engine, this VIO 80 U 8.07t machine can provide 40.7kW or 54 horse power for the crawler excavator. The VIO 80 U is categorised in the smallest machine segment in the crawler excavators category. The model's dimensions are 6.41m x 2.27m x 2.69m.

    The VIO 80 U is manufactured and distributed with Blade and Aircondition. Quick hitch mech., Track adaption and Material Handling Excavator are not provided on this model as of 2016. There are more detailed specifications and machine descriptions available in the original Yanmar VIO 80 U specs data sheet. You can download it for free in German on LECTURA Specs.

    The production stopped in 2016, where this VIO 80 U was available at a new list price between €79000 and €101000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

    Yanmar currently produces 4 other crawler excavators, which range from 8.1t up to 10.4t - the most visited on LECTURA Specs are SV 100-2 CR, B 7 -6 CR, SV 100-2 PBCR. Throughout the production cycle of this VIO 80 U crawler excavator, there have been around 4 models that average a price of €48000 for an age of 5 years Want more detailed specifications? Download the latest Yanmar VIO 80 U specs data sheet on LECTURA Specs today!

    Technical specs - VIO 80 U Yanmar


    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Weight 8.07 t
    • Transport length 6.41 m
    • Transport width 2.27 m
    • Transport height 2.69 m
    • Track width 450 mm
    • Max. Reach horizontal 4,7 m
    • Dredging depth 4,1 m
    • Engine manuf. Yanmar
    • Engine type 4TNV98
    • Engine power 40.7 kW
    • Displacement 3.32 l
    • Revolutions at max torque 2000 rpm

    More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, tear-out force, bucket width, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

    Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

    Special equipment

    • Diesel particulate filter
    • Track adjustment
    • Blade
    • Cabin adjustment
    • Overload alert
    • Material Handling Excavator
    • Aircondition
    • Quick hitch hydr.
    • Quick hitch mech.

    Carbon footprint calculator for Crawler Excavators

    Use the ERA equipment CO2 Calculator to find out the carbon emissions per hour of use of the Yanmar VIO 80 U or alternative Crawler Excavators.

    The footprint evaluation can be performed considering different biofuel scenarios or other variables.

    or visit the ERA Equipment CO2 Calculator to calculate how to optimise your CO2 emissions.

    service provided by ERA



    Good and easy machine to operate

    Yanmar VIO 80 U user from
