ViO82 Yanmar excavator specs & Dimensions (2019 - 2024)

Yanmar ViO82 is a Crawler Excavator manufactured since 2019, with a weight of 8.38 t and a track width of 450 mm. Its transport di…

Yanmar ViO82 is a Crawler Excavator manufactured since 2019, with a weight of 8.38 t and a track width of 450 mm. Its transport dimensions are 4.97 m in length, 2.27 m in width, and 2.75 m in height. The excavator has a tear-out force of 50.4 kN, a dredging depth of 4.4 m, and a maximum horizontal reach of 4.62 m. It features a bucket capacity of 0.28 m³ and comes equipped with a blade and a diesel particulate filter.

Crawler Excavators Yanmar ViO82

Technical specs - ViO82 Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.38 t
Transport length
4.97 m
Transport width
2.27 m
Transport height
2.75 m
Bucket capacity
0.28 m³
Track width
450 mm
Max. Reach horizontal
4.62 m
Dredging depth
4.4 m
Tear-out force
50.4 kN
Model series
VIO
Engine manuf.
Yanmar
Engine type
4TNV98C-WBV1
Engine power
42.4 kW
Emission level
Tier 4

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Yanmar ViO82 FAQ

When was the Yanmar ViO82 manufactured?

The Yanmar ViO82 was manufactured from 2019 to 2024.

How much does the Yanmar ViO82 weigh?

The Yanmar ViO82 weighs 8.38 tons.

What are the transport dimensions of the Yanmar ViO82 crawler excavator?

The Yanmar ViO82 has a transport length of 4.97 meters, a transport width of 2.27 meters, and a transport height of 2.75 meters.

What is the track width of the Yanmar ViO82 crawler excavator?

The Yanmar ViO82 crawler excavator has a track width of 450 mm.

What are the dredging depth and maximum horizontal reach of the Yanmar ViO82?

The Yanmar ViO82 has a dredging depth of 4.4 meters and a maximum horizontal reach of 4.62 meters.

What is the tear-out force of the Yanmar ViO82?

The Yanmar ViO82 has a tear-out force of 50.4 kN.

What is the bucket capacity of the Yanmar ViO82 excavator?

The Yanmar ViO82 excavator has a bucket capacity of 0.28 cubic meters.
