SV 85 2PB Yanmar excavator specs & Dimensions (2016 - 2020)

Yanmar SV 85 2PB is a crawler excavator manufactured from 2016 to 2020. It has a weight of 8.6 tons and a track width of 450 mm. T…

Yanmar SV 85 2PB is a crawler excavator manufactured from 2016 to 2020. It has a weight of 8.6 tons and a track width of 450 mm. The transport dimensions are 6.11 meters in length, 2.33 meters in width, and 2.6 meters in height. The excavator features a tear-out force of 53.2 kN, a dredging depth of 4.32 meters, and a maximum horizontal reach of 3.55 meters. Special equipment includes air conditioning, a blade, a diesel particulate filter, an overload alert, and both hydraulic and mechanical quick hitches.

Crawler Excavators Yanmar SV 85 2PB

Technical specs - SV 85 2PB Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.6 t
Transport length
6.11 m
Transport width
2.33 m
Transport height
2.6 m
Undercarriage
SL
Track width
450 mm
Boom
VA
Max. Reach horizontal
3.55 m
Dredging depth
4.32 m
Tear-out force
53.2 kN
Model series
SV
Engine manuf.
Deutz
Engine type
TCD2.9 L4
Engine power
55.4 kW
Revolutions at max torque
2600 rpm
Max. torque
300/1600 Nm
No. of cylinders
4
Emission level
Tier 4 f

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, dimension lxwxh, displacement, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
Yes

Download datasheets (PDF)

Yanmar SV 85 2PB FAQ

When was the Yanmar SV 85 2PB manufactured?

The Yanmar SV 85 2PB was manufactured from 2016 to 2020.

How much does the Yanmar SV 85 2PB weigh?

The Yanmar SV 85 2PB weighs 8.6 tons.

What are the transport dimensions of the Yanmar SV 85 2PB?

The Yanmar SV 85 2PB has a transport length of 6.11 meters, a transport width of 2.33 meters, and a transport height of 2.6 meters.

What are the undercarriage specifications of the Yanmar SV 85 2PB?

The Yanmar SV 85 2PB has a standard undercarriage with a track width of 450 mm.

What are the excavation performance specifications of the Yanmar SV 85 2PB?

The Yanmar SV 85 2PB has a dredging depth of 4.32 meters, a maximum horizontal reach of 3.55 meters, and features an adjustable boom.

What is the tear-out force of the Yanmar SV 85 2PB?

The Yanmar SV 85 2PB has a tear-out force of 53.2 kN.

How much is a Yanmar SV 85 2PB Crawler excavator (2016u20132020) worth?

The residual value of the Yanmar SV 85 2PB depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
