B7-6 Yanmar excavator specs & Dimensions (2022 - 2025)

Weight: 8.2t – Transport length: 6.2m – Transport width: 2.27m – Transport height: 2.68m – Track width: 450mm – Boom: SKA…

Weight: 8.2t – Transport length: 6.2m – Transport width: 2.27m – Transport height: 2.68m – Track width: 450mm – Boom: SKA

Check out detailed specifications, information and technical data for Yanmar B7-6 excavator manufactured between 2022 - 2025. Get more in-depth insight with Yanmar B7-6 digger specifications. See information, like: Weight: 8.2t – Transport length: 6.2m – Transport width: 2.27m – Transport height: 2.68m – Track width: 450mm – Boom: SKA and more.

Crawler Excavators Yanmar B7-6
Crawler Excavators Yanmar B7-6
Crawler Excavators Yanmar B7-6
Crawler Excavators Yanmar B7-6
Crawler Excavators Yanmar B7-6
Crawler Excavators Yanmar B7-6
Crawler Excavators Yanmar B7-6
Crawler Excavators Yanmar B7-6
Crawler Excavators Yanmar B7-6
Crawler Excavators Yanmar B7-6

Technical specs - B7-6 Yanmar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.2 t
Transport length
6.2 m
Transport width
2.27 m
Transport height
2.68 m
Track width
450 mm
Boom
SKA
Max. Reach horizontal
6.37 m
Dredging depth
4.45 m
Tear-out force
56.9 kN
Model series
B
Engine manuf.
Yanmar
Engine type
4TNV98C-WBV
Engine power
39.3 kW
Displacement
3.318 l
Revolutions at max torque
1900 rpm
Max. torque
241 Nm
No. of cylinders
4

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, bucket width, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Yanmar B7-6 FAQ

When was the Yanmar B7-6 manufactured?

The Yanmar B7-6 was first produced in 2024.

How much does the Yanmar B7-6 weigh?

The Yanmar B7-6 weighs 8.2 tons.

What are the transport dimensions of the Yanmar B7-6 crawler excavator?

The Yanmar B7-6 has a transport length of 6.2 meters, a transport width of 2.27 meters, and a transport height of 2.68 meters.

What is the track width of the Yanmar B7-6 crawler excavator?

The Yanmar B7-6 crawler excavator has a track width of 450 mm.

What are the excavation performance specifications of the Yanmar B7-6 crawler excavator?

The Yanmar B7-6 crawler excavator has a dredging depth of 4.45 meters, a maximum horizontal reach of 6.37 meters, and features a lateral articulated boom.

What is the tear-out force of the Yanmar B7-6?

The Yanmar B7-6 has a tear-out force of 56.9 kN.

How much is a Yanmar B7-6 Crawler excavator (2024u20132025) worth?

The residual value of the Yanmar B7-6 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
