SE205W Shantui excavator specs & Dimensions (2023 - 2026)

Weight: 21.2t – Transport length: 9.625m – Transport width: 2.8m – Transport height: 3.1m – Bucket capacity: 0.9m³ – Track width: …

Weight: 21.2t – Transport length: 9.625m – Transport width: 2.8m – Transport height: 3.1m – Bucket capacity: 0.9m³ – Track width: 600mm

Check out detailed specifications, information and technical data for Shantui SE205W excavator manufactured between 2023 - 2026. Get more in-depth insight with Shantui SE205W digger specifications. See information, like: Weight: 21.2t – Transport length: 9.625m – Transport width: 2.8m – Transport height: 3.1m – Bucket capacity: 0.9m³ – Track width: 600mm and more.

Crawler Excavators Shantui SE205W

Technical specs - SE205W Shantui

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21.2 t
Transport length
9.625 m
Transport width
2.8 m
Transport height
3.1 m
Bucket capacity
0.9 m³
Track width
600 mm
Max. Reach horizontal
9.675 m
Dredging depth
6.49 m
Tear-out force
137 kN
Bucket width
1.25 m
Engine manuf.
Weichai
Engine type
WP4.6N
Engine power
129 kW
Displacement
4.58 l
No. of cylinders
4
Emission level
Tier 3 / Stage III

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, model series, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Shantui SE205W FAQ

When was the Shantui SE205W manufactured?

The Shantui SE205W was first produced in 2023.

How much does the Shantui SE205W weigh?

The Shantui SE205W weighs 21.2 tons.

What are the transport dimensions of the Shantui SE205W crawler excavator?

The Shantui SE205W has a transport length of 9.63 meters, a width of 2.8 meters, and a height of 3.1 meters.

What are the excavation performance specifications of the Shantui SE205W?

The Shantui SE205W has a dredging depth of 6.42 meters and a maximum horizontal reach of 10.07 meters.

What is the tear-out force of the Shantui SE205W?

The tear-out force of the Shantui SE205W is 137 kN.

What is the bucket capacity of the Shantui SE205W crawler excavator?

The Shantui SE205W crawler excavator has a bucket capacity of 0.9 cubic meters.

How much is a Shantui SE205W Crawler excavator (2023u20132025) worth?

The residual value of the Shantui SE205W depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
