R 926 Liebherr excavator specs & Dimensions (2012 - 2016)

Model rating
8,50 / 10

Liebherr R 926 is a Crawler Excavator manufactured from 2012 to 2016. It has a weight of 25.3 tons and a track width of 600 mm. Th…

Liebherr R 926 is a Crawler Excavator manufactured from 2012 to 2016. It has a weight of 25.3 tons and a track width of 600 mm. The transport dimensions are 9.4 meters in length, 2.38 meters in width, and 3.07 meters in height. The machine features a tear-out force of 103 kN, a dredging depth of 6.85 meters, and a maximum horizontal reach of 9.7 meters. The bucket width is 1.05 meters with a capacity of 0.8 cubic meters. Special equipment includes air conditioning.

Crawler Excavators Liebherr R 926
Crawler Excavators Liebherr R 926
Crawler Excavators Liebherr R 926
Crawler Excavators Liebherr R 926
Crawler Excavators Liebherr R 926
Crawler Excavators Liebherr R 926

Visit Liebherr live at

Technical specs - R 926 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
25.3 t
Transport length
9.4 m
Transport width
2.38 m
Transport height
3.07 m
Bucket capacity
0.8 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
9.7 m
Dredging depth
6.85 m
Tear-out force
103 kN
Bucket width
1.05 m
Model series
R
Engine manuf.
Liebherr
Engine type
D934 A7
Engine power
120 kW
Displacement
4.58 l
Revolutions at max torque
1800 rpm
No. of cylinders
4
Cylinder bore x stroke
108x125 mm
Emission level
IIIB

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, max. torque are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr R 926 FAQ

When was the Liebherr R 926 manufactured?

The Liebherr R 926 was manufactured from 2012 to 2016.

How much does the Liebherr R 926 weigh?

The Liebherr R 926 weighs 25.3 tons.

What are the transport dimensions of the Liebherr R 926 crawler excavator?

The Liebherr R 926 crawler excavator has a transport length of 9.4 meters, a transport width of 2.38 meters, and a transport height of 3.07 meters.

What is the fuel consumption range of the Liebherr R 926 crawler excavator?

The fuel consumption range of the Liebherr R 926 crawler excavator is between 10 and 18 liters per hour.

What are the undercarriage specifications of the Liebherr R 926?

The Liebherr R 926 has a long undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Liebherr R 926 crawler excavator?

The Liebherr R 926 crawler excavator has a dredging depth of 6.85 meters, a maximum horizontal reach of 9.7 meters, and is equipped with a monobloc boom.

What are the power ratings of the Liebherr R 926?

The source data does not provide power ratings for the Liebherr R 926.

What are the specifications of the primary work tool bucket on the Liebherr R 926?

The primary work tool bucket of the Liebherr R 926 has a capacity of 0.8 cubic meters and a width of 1.05 meters.

How much is a Liebherr R 926 Crawler excavator (2012u20132016) worth?

The residual value of the Liebherr R 926 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
