R 926 Compact Litronic Liebherr excavator specs & Dimensions (2021 - 2026)

Liebherr R 926 Compact Litronic is a crawler excavator manufactured since 2021. It has a weight of 25.55 tons and a track width of…

Liebherr R 926 Compact Litronic is a crawler excavator manufactured since 2021. It has a weight of 25.55 tons and a track width of 600 mm. The transport dimensions are 9 meters in length, 3.29 meters in width, and 3.085 meters in height. The machine features a dredging depth of 6.26 meters and a maximum horizontal reach of 9.18 meters. The bucket width is 1.4 meters, with a capacity ranging from 0.55 to 1.5 cubic meters. Special equipment includes air conditioning, a diesel particulate filter, and an overload alert system.

Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic
Crawler Excavators Liebherr R 926 Compact Litronic

Visit Liebherr live at

Technical specs - R 926 Compact Litronic Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
25.55 t
Transport length
9 m
Transport width
3.29 m
Transport height
3.085 m
Bucket capacity
1.5 m³
Bucket capacity min.
0.55 m³
Bucket capacity max.
1.5 m³
Track width
600 mm
Boom
VA
Max. Reach horizontal
9.18 m
Dredging depth
6.26 m
Bucket width
1.4 m
Model series
R
Engine manuf.
Liebherr
Engine type
D924 A7-05
Engine power
129 kW
Displacement
4.5 l
Revolutions at max torque
1400 rpm
Max. torque
682 Nm
No. of cylinders
4
Cylinder bore x stroke
104x132 mm
Emission level
Stage V

More technical details, like: undercarriage, tear-out force, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr R 926 Compact Litronic FAQ

When was the Liebherr R 926 Compact Litronic manufactured?

The Liebherr R 926 Compact Litronic was first produced in 2021.

How much does the Liebherr R 926 Compact Litronic weigh?

The Liebherr R 926 Compact Litronic weighs 25.55 tons.

What are the transport dimensions of the Liebherr R 926 Compact Litronic?

The Liebherr R 926 Compact Litronic has a transport length of 9 meters, a transport width of 3.29 meters, and a transport height of 3.09 meters.

What is the track width of the Liebherr R 926 Compact Litronic's undercarriage?

The Liebherr R 926 Compact Litronic has a track width of 600 mm.

What are the excavation performance specifications of the Liebherr R 926 Compact Litronic?

The Liebherr R 926 Compact Litronic has a dredging depth of 6.26 meters, a maximum horizontal reach of 9.18 meters, and features an adjustable boom.

What are the specifications of the bucket on the Liebherr R 926 Compact Litronic?

The bucket of the Liebherr R 926 Compact Litronic has a capacity ranging from 0.55 to 1.5 cubic meters and a width of 1.4 meters.

How much is a Liebherr R 926 Compact Litronic Crawler excavator (2021u20132025) worth?

The residual value of the Liebherr R 926 Compact Litronic depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
