HMK 220 LC Hidromek excavator specs & Dimensions (2011 - 2020)

Hidromek HMK 220 LC is a Crawler Excavator manufactured from 2011 to 2020. It has a weight of 23.35 tons and a track width of 600 …

Hidromek HMK 220 LC is a Crawler Excavator manufactured from 2011 to 2020. It has a weight of 23.35 tons and a track width of 600 mm. The transport dimensions are 9.79 meters in length, 2.99 meters in width, and 2.985 meters in height. The excavator features a tear-out force of 120.62 kN, a dredging depth of 6.67 meters, and a maximum horizontal reach of 10.05 meters. The bucket width is 1.2 meters with a capacity of 1 cubic meter. Special equipment includes air conditioning, cabin adjustment, a diesel particulate filter, material handling capabilities, an overload alert, hydraulic and mechanical quick hitches, and track adjustment.

Crawler Excavators Hidromek HMK 220 LC
Crawler Excavators Hidromek HMK 220 LC
Crawler Excavators Hidromek HMK 220 LC
Crawler Excavators Hidromek HMK 220 LC
Crawler Excavators Hidromek HMK 220 LC
Crawler Excavators Hidromek HMK 220 LC
Crawler Excavators Hidromek HMK 220 LC
Crawler Excavators Hidromek HMK 220 LC
Crawler Excavators Hidromek HMK 220 LC
Crawler Excavators Hidromek HMK 220 LC

Visit Hidromek live at

Technical specs - HMK 220 LC Hidromek

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
23.35 t
Transport length
9.79 m
Transport width
2.99 m
Transport height
2.985 m
Bucket capacity
1 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
10.05 m
Dredging depth
6.67 m
Tear-out force
120.62 kN
Bucket width
1.2 m
Model series
HMK
Engine manuf.
Isuzu
Engine type
AI-4HK1X
Engine power
128.4 kW
Displacement
5.193 l
Revolutions at max torque
1500 rpm
Max. torque
674 Nm
No. of cylinders
4

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
Yes
Blade
No
Cabin adjustment
Yes
Overload alert
Yes
Material Handling Excavator
Yes
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
Yes

Download datasheets (PDF)

Hidromek HMK 220 LC FAQ

When was the Hidromek HMK 220 LC manufactured?

The Hidromek HMK 220 LC was manufactured from 2011 to 2020.

How much does the Hidromek HMK 220 LC weigh?

The Hidromek HMK 220 LC weighs 23.35 tons.

What are the transport dimensions of the Hidromek HMK 220 LC?

The transport dimensions of the Hidromek HMK 220 LC are 9.79 meters in length, 2.99 meters in width, and 2.99 meters in height.

What are the undercarriage specifications of the Hidromek HMK 220 LC?

The Hidromek HMK 220 LC has a long undercarriage and a track width of 600 mm.

What are the excavation performance specifications of the Hidromek HMK 220 LC?

The Hidromek HMK 220 LC has a dredging depth of 6.67 meters, a maximum horizontal reach of 10.05 meters, and features a Monobloc boom.

What are the power ratings of the Hidromek HMK 220 LC?

The power ratings of the Hidromek HMK 220 LC are not provided in the available data.

What are the bucket specifications of the Hidromek HMK 220 LC?

The Hidromek HMK 220 LC has a bucket capacity of 1 cubic meter and a bucket width of 1.2 meters.

How much is a Hidromek HMK 220 LC Crawler excavator (2011u20132020) worth?

The residual value of the Hidromek HMK 220 LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
