215 LC-SR Atlas excavator specs & Dimensions (2011 - 2021)

Atlas 215 LC-SR is a Crawler Excavator manufactured from 2011 to 2021. It has a weight of 21.8 tons and a track width of 800 mm. T…

Atlas 215 LC-SR is a Crawler Excavator manufactured from 2011 to 2021. It has a weight of 21.8 tons and a track width of 800 mm. The transport dimensions are 8.25 meters in length, 3 meters in width, and 3.2 meters in height. The tear-out force is 81 kN, and the bucket width is 1 meter. Special equipment includes air conditioning, a diesel particulate filter, and an overload alert system.

Crawler Excavators Atlas 215 LC-SR
Crawler Excavators Atlas 215 LC-SR
Crawler Excavators Atlas 215 LC-SR
Crawler Excavators Atlas 215 LC-SR
Crawler Excavators Atlas 215 LC-SR
Crawler Excavators Atlas 215 LC-SR

Visit Atlas live at

Technical specs - 215 LC-SR Atlas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21.8 t
Transport length
8.25 m
Transport width
3 m
Transport height
3.2 m
Bucket capacity
0.82 m³
Undercarriage
LC
Track width
800 mm
Boom
VA
Max. Reach horizontal
9.4 m
Dredging depth
6.05 m
Tear-out force
81 kN
Bucket width
1 m
Engine manuf.
Deutz
Engine type
TCD6.1
Engine power
115 kW
Displacement
4.04 l
Revolutions at max torque
1800 rpm
No. of cylinders
4
Emission level
Tier 4 f

More technical details, like: bucket capacity min., bucket capacity max., model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Atlas 215 LC-SR FAQ

When was the Atlas 215 LC-SR manufactured?

The Atlas 215 LC-SR was manufactured from 2011 to 2021.

How much does the Atlas 215 LC-SR weigh?

The Atlas 215 LC-SR weighs 21.8 tons.

What are the transport dimensions of the Atlas 215 LC-SR?

The Atlas 215 LC-SR has a transport length of 8.25 meters, a transport width of 3 meters, and a transport height of 3.2 meters.

What are the undercarriage specifications of the Atlas 215 LC-SR?

The Atlas 215 LC-SR has a long undercarriage with a track width of 800 mm.

What are the excavation performance specifications of the Atlas 215 LC-SR?

The Atlas 215 LC-SR has a dredging depth of 6.05 meters, a maximum horizontal reach of 9.4 meters, and features an adjustable boom.

What is the tear-out force of the Atlas 215 LC-SR?

The Atlas 215 LC-SR has a tear-out force of 81 kN.

What are the specifications of the primary work tool bucket on the Atlas 215 LC-SR?

The primary work tool bucket of the Atlas 215 LC-SR has a capacity of 0.82 cubic meters and a width of 1 meter.

How much is a Atlas 215 LC-SR Crawler excavator (2011u20132021) worth?

The residual value of the Atlas 215 LC-SR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
