YC22-9 Yuchai excavator specs & dimensions (2020 - 2026)

Yuchai YC22-9 is a mini excavator manufactured since 2020. It has a weight of 2.18 tons and a track width of 250 mm. The transport…

Yuchai YC22-9 is a mini excavator manufactured since 2020. It has a weight of 2.18 tons and a track width of 250 mm. The transport dimensions are 4.12 meters in length, 1.3 meters in width, and 2.29 meters in height. The machine features a tear-out force of 14.9 kN, a dredging depth of 2.62 meters, and a maximum horizontal reach of 4.39 meters. The bucket width is 0.555 meters with a capacity of 0.09 cubic meters. Special equipment includes a blade and rubber tracks.

Mini Excavators Yuchai YC22-9

Technical specs - YC22-9 Yuchai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.18 t
Transport length
4.12 m
Transport width
1.3 m
Transport height
2.29 m
Bucket capacity
0.09 m³
Bucket width
0.555 m
Track width
250 mm
Driver protection
FD
Max. Reach horizontal
4.39 m
Dredging depth
2.62 m
Tear-out force
14.9 kN
Engine manuf.
Laidong
Engine type
3TE28
Engine power
20.5 kW

More technical details, like: bucket capacity min., bucket capacity max., standard tyres, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Yuchai YC22-9 FAQ

When was the Yuchai YC22-9 manufactured?

The Yuchai YC22-9 was first produced in 2020.

How much does the Yuchai YC22-9 mini excavator weigh?

The Yuchai YC22-9 mini excavator weighs 2.18 tons.

What are the transport dimensions of the Yuchai YC22-9 mini excavator?

The Yuchai YC22-9 has a transport length of 4.12 meters, a transport width of 1.3 meters, and a transport height of 2.29 meters.

What is the track width of the Yuchai YC22-9's undercarriage?

The Yuchai YC22-9 has a track width of 250 mm.

What are the excavation performance specifications of the Yuchai YC22-9 mini excavator?

The Yuchai YC22-9 mini excavator has a dredging depth of 2.62 meters and a maximum horizontal reach of 4.39 meters.

What is the tear-out force of the Yuchai YC22-9 mini excavator?

The Yuchai YC22-9 mini excavator has a tear-out force of 14.9 kN.

What are the bucket specifications of the Yuchai YC22-9 mini excavator?

The Yuchai YC22-9 mini excavator has a bucket capacity of 0.09 cubic meters and a bucket width of 0.555 meters.

What operator safety and support features does the Yuchai YC22-9 have?

The Yuchai YC22-9 is equipped with a canopy for driver protection.
