Technical specs - ET 20 Wacker Neuson
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 1.96 t
- Transport length
- 4.05 m
- Transport width
- 0.99 m
- Transport height
- 2.29 m
- Bucket width
- 0.6 m
- Track width
- 230 mm
- Driver protection
- FD
- Max. Reach horizontal
- 4.13 m
- Dredging depth
- 2.49 m
- Tear-out force
- 18.8 kN
- Model series
- ET
- Engine manuf.
- Yanmar
- Engine type
- 3TNV76
- Engine power
- 13.2 kW
- Displacement
- 1.116 l
- Revolutions at max torque
- 2200 rpm
- No. of cylinders
- 3
More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., standard tyres, dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with standard bucket
Special equipment
- Track adjustment
-
Yes
- Rubber track
-
Yes
- Blade
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
Download datasheets (PDF)
Wacker Neuson ET 20 FAQ
How much does the Wacker Neuson ET 20 weigh?
What are the transport dimensions of the Wacker Neuson ET 20 mini excavator?
What is the track width of the Wacker Neuson ET 20's undercarriage?
What is the excavation performance of the Wacker Neuson ET 20?
What is the tear-out force of the Wacker Neuson ET 20 mini excavator?
What is the bucket width of the Wacker Neuson ET 20 mini excavator?
What operator safety and support features does the Wacker Neuson ET 20 have?
How much is a Wacker Neuson ET 20 Mini excavator (2012u20132017) worth?
