Volvo ECR58 is a mini excavator manufactured since 2021, with a weight of 5.84 tons. It features a track width of 400 mm, a transp…
Volvo ECR58 is a mini excavator manufactured since 2021, with a weight of 5.84 tons. It features a track width of 400 mm, a transport length of 6.105 meters, a transport width of 2 meters, and a transport height of 2.54 meters. The machine has a tear-out force of 41.2 kN, a dredging depth of 3.957 meters, and a maximum horizontal reach of 5.972 meters. The bucket width is 0.6 meters with a capacity of 0.14 cubic meters. Special equipment includes a blade and rubber tracks.
What are the transport dimensions of the Volvo ECR58 mini excavator?
The Volvo ECR58 has a transport length of 6.11 meters, a transport width of 2 meters, and a transport height of 2.54 meters.
What is the track width of the Volvo ECR58 mini excavator?
The Volvo ECR58 mini excavator has a track width of 400 mm.
What are the excavation performance specifications of the Volvo ECR58?
The Volvo ECR58 has a dredging depth of 3.957 meters and a maximum horizontal reach of 5.972 meters.
What is the tear-out force of the Volvo ECR58 mini excavator?
The Volvo ECR58 mini excavator has a tear-out force of 41.2 kN.
What are the bucket specifications of the Volvo ECR58 mini excavator?
The Volvo ECR58 has a bucket capacity of 0.14 cubic meters and a bucket width of 0.6 meters.
What operator safety and support features does the Volvo ECR58 have?
The Volvo ECR58 provides operator safety through a protective cabin.
How much is a Volvo ECR58 Mini excavator (2021u20132025) worth?
The residual value of the Volvo ECR58 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
Volvo ECR58 overview
Volvo ECR58 features overview
STANDARD EQUIPMENT Engine Drivetrain Electric / Electronic control system Swing system Undercarriage Hydraulic system In Volvo 4-cylinder, vertical, inline, electronically controlled, diesel engine; meets EU Stage V or EPA Tier 4f environmental regulations. Diesel oxidation catalyst and diesel particulate filter exhaust system according to treatment system with 6000 hours service interval. Engine restart pre-bugging system: Starter motor is protected against ignition when the engine is already running. Safe engine start function: The left console must be raised to operate the starter. Time adjustable auto idling system. Eco Mode. Dry type dual element air filter. Plastic fuel tank with drain plug. Protective screen on fuel fill tube. Fuel filter with water separator. Axial piston hydraulic motors equipped with an epicyclic reduction gear. Automatic two speed travel. Multidisc track brakes, spring thread and hydraulic released. 5 ground fl ow rollers lubricated for life. Lubricating stress wheel lubricant for life. Maintenance free battery. IP67 protected electrical system and high quality connectors. Battery cut switch guarded in key compartment. In cab 12V power stub & one front cooling unit. STANDARD EQUIPMENT Digging equipment Instrumentation and monitoring Machine control system Official approval FOPS on top level 1 (Falling Object Protect the structure). TOPS (Tip-Over Protective Structure), ROPS (Roll Override Guard) up to RoPS (Roll Wear Protection Structure); Cusioned Operator Station. Height Adjustable Seat, Consoles and Joysticks; all suspended together. Retractable 50mm orange seat belt with warning indicator. High Visibility Visible Orange Handrail and Cab Entry Step Up. Large Door Access. Large and spacious uncluttered floor with easy cleaning floor mat easy to clean. Gas strut assisted front window opening. Fully open front gear with in cab storage for forward lower window. Front windscreen wiper and underlay screws. Front windshield wiper and wash system. Right side side sliding window. Heating System. Several customizable air fans. Filtered air intake with large size and easily replaceable element replacement inner part. Driver light inside interior light. LCD locking lock locked into keypad door compartment Big Air Ventilatores according to EN 6
Engine / Driveline and transmission
Profit boosting technology A range of smart features combine to deliver outstanding fuel efficiency, including the advanced hydraulic system with load sensing and flow sharing. ECO mode further reduces fuel consumption by up to 10% while auto idle eliminates unnecessary fuel usage. Auto-engine shutdown means no hours are recorded, reducing maintenance costs whilst contributing to a higher resale value. Outstanding fuel efficiency Advanced Hydraulic System with Load Sensing and Flow Sharing NEW, Eco Mode NEW, Auto Engine Shutdown NEW,
Hydraulics
Precision controls Whether for quick bulk digging or precise leveling, the new hydraulic system on the ECR58 offers excellent combined operations. Operate hydraulic attachments with precision thanks to proportional fingertip controls. The automotive jogwheel and 5 colour display allow intuitive navigation through the menus for further fine-tuning; so the ECR58 can be adjusted to any work requirement. Top of the class Superior stability, breakout force, tear down force and lifting capacity make the F-generation ECR58 a top performer in its class. Experience fast cycle times even during tough operations and heavy loads. High system pressure delivers impressive tractive effort when climbing inclines or traveling over rough terrain. Take on more Switch quickly between attachments and take over a variety of tasks in the F generation ECR58, thanks to preset adjustments on the new 5 display. Hydraulic flow settings can be easily customized ensuring optimal performance for the attachment you work with. Precision controls Intuitive jogwheel and 5 colour display NEW, Proportional fingertip controls, Smooth combined movements Top of the class True 6t class performance, Low center of gravity for excellent stability NEW, Superior breakout/tipping forces and lifting capacities NEW, High system pressure delivers impressive tractive effort, short swing radius.
Work modes to match machine settings to accessories in use
•
Bucket or grapple change over valve
o
Second accessory circuit
o
Third accessory circuit (for side tilting quick coupler)
o
Secondary relief valves for auxiliaries (22 MPa)
•
Hydraulic drain including flat face coupling for accessories
o
Flat face hydaulic quick couplings for main and second acces- sories circuits
o
Single acting circuit for quick couplers
o
Double acting circuit for quick couplers
o
Boom and arm safety lifting valves with overload indicator
o
Boom
arm and dozer blade safety lifting valves with overload indicator"
o
Safety valve certification
o
Mineral hydraulic oil VG46
o
Bio hydraulic oil VG46 (PANOLIN®)
o
Mineral hydraulic oil VG68
o
Mineral hydraulic oil VG32
o
Bio hydraulic oil VG32 (PANOLIN®)
o
Operator environment
Cab with heater
•
Cab with heater and manual air conditioning
o
Vinyl high back seat
o
Textile high back seat
o
Head rest
o
3” Seat belt
o
Height adjustable arm rest
•
Large size monoblock travel pedals
•
Bottle holder
•
Large capacity storage box
•
Lockable backrest storage box
o
Net
•
Coat hook
•
Ceiling light
•
Radio preparation
•
Radio (AUX
USB
SD
Bluetooth
DAB)"
o
1 x 12V power socket
•
2 x USB charging ports
•
Control pattern change
o
Travel alarm
o
Codelocked anti-theft device
o
Additional hour meter
o
Large capacity
key-lockable toolbox"
•
Undercarriage
400mm rubber tracks
o
400mm rubber pads on steel chain
o
380mm steel tracks
o
400mm add-on rubber pads on steel shoe
o
Standard dozer blade
•
Floating dozer blade
o
Other features
Solutions for you Our industry leading machines are just the beginning of your relationship with Volvo. As your partner, we have developed an extensive range of additional solutions to help you improve uptime, increase productivity and lower costs. Designed for your business Our nine-block portfolio of products and services has been designed to complement the performance of your machine and boost your profitability. Simply put, we offer some of the best warranties, warranties and technological solutions in today's industry. There when you need us Whether you are buying new or used, our global dealer and technician network provides 24/7 support including machine monitoring and world-class parts availability. It is the basis for everything offered by Volvo Services so you can be sure we've covered you right from the start. Machine monitoring made easy With caretrack, volvo telematics system, you can remotely monitor the status of your machine, including engine, fuel efficiency, vital safety information and machine health. Distribute service costs and keep your machine in top condition with a repair and maintenance agreement. Here to support you Volvo is here to assist you with a range of services, including financial services and easily available Genuine Volvo Parts the best choice for your Volvo machine. Talk to your local dealer to find out more about the range of services they can offer so your business can succeed. The industry's best cab Enter the most spacious cabin in the industry. The Volvo cab is designed to provide highest levels of operator comfort and features efficient sound dampening, upgraded ergonomic controls, numerous storage areas as well as 12V/USB ports. The multi-adjustable seat and console, both mounted on the same suspension, ensure excellent shock and vibration absorption. A fully opening front window and sliding side add added value to convenience and visibility. together A VOLVO EXCLUSIVE The most spacious cab in the industry NEW, suspended seat and consoles, Large travel pedals, storage boxes, 12V and USB ports NEW, Best-in-class all round visibility, Quiet In-cab environment. Volvo Services caretrack: machine monitoring made easy, maintenance and repair agreements, Genuine Volvo Parts, Financial Services.
Tables
Machine exterior
Right rearview mirror
o
Left rearview mirror
o
Front left LED workligt on cab roof
•
Front right LED workligt on cab roof
o
Rear right LED worklight on cab roof
o
Amber flashing LED beacon
o
2 x cab mounted LED worklights illuminating left & right sides of the machine
o
Green flashing LED beacon (lights-up when to operator has buckled the seat belt)
o
Protected LED worklight on the boom
o
Additional counterweight
o
Several level of paint customisation (RAL specifications) to match with your corporate identity
o
Digging equipment
Standard arm
o
Long arm + additional counterweight
o
Service and maintenance
In-cab diagnostick socket
•
Service reminder
•
Tool kit
o
Attachments
Volvo quick coupler mechanical or hydraulic (pin-on)
o
LH hydraulic quick coupler with lifting hook (HS03)
o
Symetrical-type hydraulic quick coupler with lifting hook (S40)
o
Hydraulic side tilting quick coupler with lifting hook (HS03 & S40)
o
Tiltrotators (S40)
o
A choice of 30cm / 62L up to 90cm / 235L general purpose buckets
o
A choice of general purpose
twin pick or spade nose teeth"
o
Bolt-on side cutters for general purpose buckets
o
A choice of fix or hydraulic tiltable ditching buckets
