ECR28 Volvo excavator specs & dimensions (2004 - 2008)

Model rating
9,00 / 10

Volvo ECR28 is a mini excavator manufactured from 2004 to 2008. It has a weight of 2.7 tons and a track width of 250 mm. The trans…

Volvo ECR28 is a mini excavator manufactured from 2004 to 2008. It has a weight of 2.7 tons and a track width of 250 mm. The transport dimensions are 4 meters in length, 1.5 meters in width, and 2.44 meters in height. The dredging depth is 2 meters, and the bucket capacity ranges from a minimum of 0.037 cubic meters to a maximum of 0.153 cubic meters.

Mini Excavators Volvo ECR28

Visit Volvo live at

Technical specs - ECR28 Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.7 t
Transport length
4 m
Transport width
1.5 m
Transport height
2.44 m
Bucket capacity min.
0.037 m³
Bucket capacity max.
0.153 m³
Track width
250 mm
Driver protection
Kb
Dredging depth
2 m
Tear-out force
11.6 kN
Model series
ECR
Engine manuf.
Volvo
Engine type
D 1.2
Engine power
13.8 kW
Displacement
1.116 l
Revolutions at max torque
2200 rpm

More technical details, like: bucket capacity, bucket width, standard tyres, max. reach horizontal, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Volvo ECR28 FAQ

When was the Volvo ECR28 manufactured?

The Volvo ECR28 was manufactured from 2004 to 2008.

How much does the Volvo ECR28 weigh?

The Volvo ECR28 weighs 2.7 tons.

What are the transport dimensions of the Volvo ECR28 mini excavator?

The Volvo ECR28 mini excavator has a transport length of 4 meters, a transport width of 1.5 meters, and a transport height of 2.44 meters.

What is the track width of the Volvo ECR28 mini excavator?

The Volvo ECR28 mini excavator has a track width of 250 mm.

What is the dredging depth capability of the Volvo ECR28 mini excavator?

The Volvo ECR28 mini excavator has a dredging depth of 2 meters.

What is the tear-out force of the Volvo ECR28 mini excavator?

The Volvo ECR28 mini excavator has a tear-out force of 11.6 kN.

What are the bucket capacity specifications of the Volvo ECR28 mini excavator?

The Volvo ECR28 mini excavator has a bucket capacity ranging from 0.04 to 0.15 cubic meters.

What operator safety and support features does the Volvo ECR28 have?

The Volvo ECR28 is equipped with a cabin that provides driver protection.

How much is a Volvo ECR28 Mini excavator (2004u20132008) worth?

The residual value of the Volvo ECR28 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
