Technical specs - TB 138 FR Takeuchi
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 3.865 t
- Transport length
- 4.77 m
- Transport width
- 1.74 m
- Transport height
- 2.565 m
- Bucket capacity
- 0.105 m³
- Track width
- 350 mm
- Driver protection
- FD
- Max. Reach horizontal
- 5.425 m
- Dredging depth
- 3.42 m
- Tear-out force
- 26.5 kN
- Model series
- TB
- Engine manuf.
- Yanmar
- Engine type
- 3TNV88
- Engine power
- 22 kW
- Displacement
- 1.642 l
- Revolutions at max torque
- 2400 rpm
- Max. torque
- 107.1 Nm
- Emission level
- EU III A/ EPA I Tier 4
More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with standard bucket
Special equipment
- Track adjustment
-
No
- Rubber track
-
Yes
- Blade
-
Yes
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
