PP60S-IX PowerPlus excavator specs & dimensions (2017 - 2026)

PowerPlus PP60S-IX is a mini excavator manufactured since 2017, with a weight of 5.7 tons. It features a track width of 376 mm, a …

PowerPlus PP60S-IX is a mini excavator manufactured since 2017, with a weight of 5.7 tons. It features a track width of 376 mm, a transport length of 5.715 meters, a transport width of 2 meters, and a transport height of 2.715 meters. The machine has a tear-out force of 25.7 kN, a dredging depth of 5.94 meters, and a maximum horizontal reach of 6.36 meters. The bucket capacity is 0.2 cubic meters. Special equipment includes air conditioning, a blade, rubber tracks, and track adjustment.

Mini Excavators PowerPlus PP60S-IX

Technical specs - PP60S-IX PowerPlus

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5.7 t
Transport length
5.72 m
Transport width
2 m
Transport height
2.72 m
Bucket capacity
0.2 m³
Track width
376 mm
Max. Reach horizontal
6.36 m
Dredging depth
5.94 m
Tear-out force
25.7 kN
Model series
PP
Engine manuf.
Yanmar
Engine type
4TNV94L
Engine power
37.3 kW
Emission level
Euro III

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, driver protection, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

PowerPlus PP60S-IX FAQ

When was the PowerPlus PP60S-IX manufactured?

The PowerPlus PP60S-IX was first produced in 2017.

How much does the PowerPlus PP60S-IX weigh?

The PowerPlus PP60S-IX weighs 5.7 tons.

What are the transport dimensions of the PowerPlus PP60S-IX mini excavator?

The PowerPlus PP60S-IX has a transport length of 5.72 meters, a transport width of 2 meters, and a transport height of 2.72 meters.

What is the track width of the PowerPlus PP60S-IX mini excavator?

The PowerPlus PP60S-IX mini excavator has a track width of 376 mm.

What are the excavation performance specifications of the PowerPlus PP60S-IX mini excavator?

The PowerPlus PP60S-IX mini excavator has a dredging depth of 5.94 meters and a maximum horizontal reach of 6.36 meters.

What is the tear-out force of the PowerPlus PP60S-IX mini excavator?

The PowerPlus PP60S-IX mini excavator has a tear-out force of 25.7 kN.

What is the bucket capacity of the PowerPlus PP60S-IX mini excavator?

The bucket capacity of the PowerPlus PP60S-IX mini excavator is 0.2 cubic meters.
