N 450 Nissan excavator specs & dimensions (1990 - 1998)

Nissan N 450 is a mini excavator manufactured since 1990. It has a weight of 4 tons and a track width of 305 mm. The transport dim…

Nissan N 450 is a mini excavator manufactured since 1990. It has a weight of 4 tons and a track width of 305 mm. The transport dimensions are 5 meters in length, 1 meter in width, and 2 meters in height. The machine features a tear-out force of 31 kN, a dredging depth of 3 meters, and a maximum horizontal reach of 5 meters. Special equipment includes a blade, rubber track, and track adjustment.

N 450

Years of manufacture: 1990—1998

Data sheet
Buy & Rent
Spare parts
Transport
News

Technical specs - N 450 Nissan

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.3 t

Transport length: 5.51 m

Transport width: 1.85 m

Transport height: 2.49 m

Bucket capacity: 0.22 m³

Bucket capacity min.: 0.22 m³

Bucket width: 0.61 m

Track width: 305 mm

Driver protection: Kb

Max. Reach horizontal: 5.74 m

Dredging depth: 3.78 m

Tear-out force: 31.4 kN

Engine manuf.: Mitsubishi

Engine type: N/A

Engine power: 30.6 kW

Displacement: 2 l

No. of cylinders: 4

More technical details, like: bucket capacity max., standard tyres, model series, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: Yes
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

N 450 Nissan Specification for North America (EN)

Nissan N 450 FAQ

When was the Nissan N 450 manufactured?

The Nissan N 450 was first produced in 1990.

How much does the Nissan N 450 mini excavator weigh?

The Nissan N 450 mini excavator weighs 4.3 tons.

What are the transport dimensions of the Nissan N 450 mini excavator?

The Nissan N 450 has a transport length of 5.51 meters, a transport width of 1.85 meters, and a transport height of 2.49 meters.

What is the track width of the Nissan N 450's undercarriage?

The Nissan N 450 has a track width of 305 mm.

What are the excavation performance specifications of the Nissan N 450 mini excavator?

The Nissan N 450 mini excavator has a dredging depth of 3.78 meters and a maximum horizontal reach of 5.74 meters.

What is the tear-out force of the Nissan N 450 mini excavator?

The Nissan N 450 mini excavator has a tear-out force of 31.4 kN.

What are the bucket specifications of the Nissan N 450 mini excavator?

The Nissan N 450 mini excavator has a bucket capacity of 0.22 cubic meters and a bucket width of 0.61 meters.

What operator safety and support features does the Nissan N 450 have?

The Nissan N 450 has a cabin for driver protection.

How much is a Nissan N 450 Mini excavator (1990u20132025) worth?

The residual value of the Nissan N 450 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Nissan N 450 overview

Hydraulics

N-230, UNIQUE EQUIPMENT: N-260, 360e rocking still 0e rear obstruction allows absolute minimal disturbance of traffic, leaving work in tight utilities, roadwork or residential areas.. Sfate the art hydraulics, offer maximum digging forces with minimum effort rubber track options. lowers reconstruction cosfs Easily through backyard gates, standard doors,Aleys Replaces handicraft and is comparable to 4 men trenches with push/s rubber tracks with low ground pressure mnmze damage to turf, walkways & brick surfacing Easy operation..360e oscillation, human develop easy transported, highly practive Quick paid for itself as a rental or contract piece So you can provide unique services Auxiliary Hydraulics offers great versatility Track width (hydr) extendable (hydr)

Tyres / Tracks

N-l50, N-090, N-350, Transportable with existing light capacity vehicles ldeal to digfoundings, at the mind Extreme Low maintenance, more profits Popular Rental and Light Contractor Equipment, Law noise levels...for use in residential or industrial environmentmenfs 10% more track on ground surtace with improved stability and lower floor pressure make for somless surtace damage Work rn spofs where other machines can't yield excellent return on investment, for more profit on each job Does the work of mahrnes 2 and 3 times the cost Travel and Hand Controls, Clean Design and More Vissibility... assures least operator fatigue Quiet, smooth, fast, compact V e r satile, Grj ar anteed to subcreasedificatterly price your engagement necesty needy handy

Dimensions and weight

MACHINE WEIGHT (OPERATING),LBS.,"11,450	6,910	1,650	2,920	5,100	6,000	7,200	9,480"
BUCKET CAPACITY (STANDARD)	\|YD.3	.33	.20	.07	09	.16	.16	.22	.29
BUCKET WIDTHS,,"24""	20""	14""	18""	18""	18""	22""	24"""
ENGINE (DIESEL)
MODEL (MITSUBISHI)		4 CYL.	4 CYL.	2 CYL.	3 CYL.	3 CYL.	4 CYL.	4 CYL.	4 CYL.
RATED OUTPUT (CONSTANT)	RPM	39 @2600	24 @2300	8.5 @ 2500	16@ 2550	20@ 2500	25 @ 2400	28 @ 2600	41 @ 2600
DISPLACEMENT	CU. IN.	122	87	29	52	65	87	87	122
FUEL TANK CAPACITY	GAL	12	8	2.4	4.5	8	8	8	12
FUEL CONSUMPTION	G/P/H	1.4	0.6	0.25	0.4	0.5	0.6	0.7	1.4
ENGINE OIL CAPACITY	QTS.	9	5	2	5	5	6	6	9
WORKING RANGE
MAX. DIGGING DEPTH,A,"13' 2""	9' 4""	5' 3""	7' 8""	8' 4""	9' 2""	10' 10""	12' 5"""
MAX. VERTICAL DIG DEPTH,B,"8' 10""	6' 3""	3' 7""",4' 11',"5' 7""	6' 1""	7' 2""	9' 3"""
MAX. DIGGING HEIGHT,C,21',"16' 9""	9' 1""",11',"12' 7""	13' 2""	14' 6""	18' 2"""
MAX. DUMPING HEIGHT,D,"15' 4""	12' 2""	6' 4""	7' 6""	8' 8""	8' 9""	9' 8""	12' 4"""
MAX. REACH,E,"18' 11""",14,"9' 2""	11' 11""	13' 11""	14' 8""	16' 5""	18' 10"""
MINIMUM TURNING RADIUS,,"3'.7""	2' 8""	2' 9""	3' 6""	4' 1""	4' 6""	6' 1""	6' 11"""
REAR END TURNING RADIUS,,,-0,"2' 9""	3' 6""	4' 1""	4' 3""",4' 8',"4' 10"""
DIMENSIONS
OVERALL LENGTH,F,"17' 5""	12' 7""	8' 11""	11 '7""	13' 7""	14' 3""	16' 2""	18' 1"""
OVERALL WIDTH,G,"6' 7""",5,"2'3.5""-2'11""	3' 3 3/8""	4' 10""	4' 10""	4' 5""	6' 1"""
OVERALL HEIGHT,H,"7' 9""",7.9,4' 7',"7' 3""	7' 9""	7' 9""	7' 9""	8' 2"""
PERFORMANCE
BUCKET DIGGING FORCE,LBS.,"7,300	4,200	1,760	2,550	3,740	3,960	4,730	7,060"
SWING SPEED	RPM	10.4	9.2	8	8	8.2	8.8	10	10
TRACTION POWER,LBS,"5,500	3,500	1,100	2,000	3,750	4,400	5,050	5,700"
TRAVEL SPEED	MPH	1.1-1.9	1.1-1.8	1.2	1- 1.6	1.1- 1.8	1.2 - 1.9	1.2 - 1.9	1.2 - 2.4
GRADEABILITY	DEGREE	30	30	25	30	30	30	30	30
SWING ANGLE	-	OFF- SET BOOM	OFF-SET BOOM	80/L 50/R	80/L 50/R	80/L 50/R	80/L 50/R	80/L 50/R	80/L 50/R
NOISE LEVEL @ 98'	DBA	69	69	67	68	68	68	69	69
HYDRAULICS
PUMP TYPE & NUMBER	GEAR	3	3	2	3	3	3	2 (VARIABLE)	3
MAIN OIL FLOW QUANTITY	GPM	2X10	1X12"	2X7.3 1×4.5	2×3	2×4	1×4.5"	6×3	6.3X3	9.5X2	2×9.8 1×9
MAIN RELIEF PRESSURE,PSI,"2,850	2,280	1,700	2,350	2,280	2,480	2,980	2,490"
AUXILIARY HYDRAULICS MAX.	GPM	N/A	N/A	6	8	12	12.6	---	19.6
HYDRAULIC OIL CAPACITY	GAL	32	19.1	3.5	5.3	13	13	13	24
LIFTING CAPACITIES
FRONT (MAX),LBS.,"4,785	4,155",900,"1,170	1,650	1,725	2,475	3,637"
SIDE (MAX),LBS,"4,275	3,262",450,615,767,"1,455	2,145	2,572"
(MAX) REACH/ FRONT,LBS,"1,650	1,860",375,660,592,843,"1,207",1.815
UNDERCARRIAGE
GROUND PRESSURE	PSI	4.6	4.3	3.2	3.2	3.3	3.6	3.8	3.8
MINIMUM GROUND CLEARANCE,,"14""	12""",6,7',"12""	12""	12""	12"""
TRACK ADJ. (GREASE CYL.)		YES	YES	SCREW	YES	YES	YES	YES	YES
TRAVEL MOTOR		AXIAL	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL
SHOE WIDTH,,"16""",12',7',9,"12""	12""	14""	16"""
STEEL TRACK		STANDARD	STANDARD		OPTIONAL	STANDARD	STANDARD	STANDARD	STANDARD
RUBBER TRACK		OPTIONAL	OPTIONAL	STANDARD	STANDARD	OPTIONAL	OPTIONAL	OPTIONAL	OPTIONAL
OTHERS
BACKFILLING BLADE,,"6'7""X16""	5'X14""	2'4""X8""	3'4""X10""	4'10""X14""	5'X14""	5'X14""	6'1""X18"""
BUCKET OPTIONS,,"12""-36""	10""-30""	8""-18""	8""-20""	10"" - 30""	10"" - 30""	12""-32""	16""-36"""
ATTACHMENT OPTIONS		YES	YES	YES	YES	YES	YES	YES	YES
CABS		STANDARD	OPTIONAL	N/A	OPTIONAL	OPTIONAL	OPTIONAL	STANDARD	STANDARD
