E55D New Holland excavator specs & dimensions (2022 - 2026)

New Holland E55D is a mini excavator manufactured since 2022, with a weight of 5.4 tons. It has a transport width of 1.9 meters an…

New Holland E55D is a mini excavator manufactured since 2022, with a weight of 5.4 tons. It has a transport width of 1.9 meters and a transport height of 2.57 meters. The machine features a tear-out force of 43 kN and a dredging depth of 3.49 meters. Special equipment includes a blade, quick hitch hydraulic, quick hitch mechanical, rubber track, and track adjustment.

Mini Excavators New Holland E55D

Technical specs - E55D New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5.4 t
Transport width
1.9 m
Transport height
2.57 m
Dredging depth
3.49 m
Tear-out force
43 kN
Model series
E
Engine manuf.
Perkins
Engine type
404J-E22T
Engine power
44 kW
Displacement
2.434 l
Revolutions at max torque
2200 rpm
No. of cylinders
4
Emission level
V

More technical details, like: transport length, bucket capacity, bucket capacity min., bucket capacity max., bucket width, track width, standard tyres, driver protection, max. reach horizontal, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
Yes

New Holland E55D FAQ

When was the New Holland E55D manufactured?

The New Holland E55D was first produced in 2022.

How much does the New Holland E55D weigh?

The New Holland E55D weighs 5.4 tons.

What are the transport dimensions of the New Holland E55D mini excavator?

The New Holland E55D has a transport width of 1.9 meters and a transport height of 2.57 meters.

What is the dredging depth of the New Holland E55D mini excavator?

The New Holland E55D mini excavator has a dredging depth of 3.49 meters.

What is the tear-out force of the New Holland E55D mini excavator?

The New Holland E55D mini excavator has a tear-out force of 43 kN.
