E10SR New Holland excavator specs & dimensions (2010 - 2015)

New Holland E10SR is a mini excavator manufactured from 2010 to 2015, with a weight of 1.06 tons. It features a track width of 180…

New Holland E10SR is a mini excavator manufactured from 2010 to 2015, with a weight of 1.06 tons. It features a track width of 180 mm, a transport length of 2.88 meters, a transport width of 0.75 meters, and a transport height of 2.19 meters. The bucket capacity is a minimum of 0.02 cubic meters, and it includes special equipment such as a blade.

Mini Excavators New Holland E10SR
Mini Excavators New Holland E10SR
Mini Excavators New Holland E10SR
Mini Excavators New Holland E10SR
Mini Excavators New Holland E10SR
Mini Excavators New Holland E10SR
Mini Excavators New Holland E10SR
Mini Excavators New Holland E10SR
Mini Excavators New Holland E10SR
Mini Excavators New Holland E10SR

Technical specs - E10SR New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.06 t
Transport length
2.88 m
Transport width
0.75 m
Transport height
2.19 m
Bucket capacity min.
0.02 m³
Track width
180 mm
Driver protection
Ü
Max. Reach horizontal
3.16 m
Dredging depth
1.75 m
Model series
E
Engine manuf.
Yanmar
Engine type
k.A.
Engine power
6 kW
Displacement
0.6 l

More technical details, like: bucket capacity, bucket capacity max., bucket width, standard tyres, tear-out force, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

New Holland E10SR FAQ

When was the New Holland E10SR manufactured?

The New Holland E10SR was manufactured from 2010 to 2015.

How much does the New Holland E10SR weigh?

The New Holland E10SR weighs 1.06 tons.

What are the transport dimensions of the New Holland E10SR mini excavator?

The New Holland E10SR has a transport length of 2.88 meters, a transport width of 0.75 meters, and a transport height of 2.19 meters.

What is the track width of the New Holland E10SR mini excavator?

The New Holland E10SR mini excavator has a track width of 180 mm.

What are the excavation performance specifications of the New Holland E10SR mini excavator?

The New Holland E10SR mini excavator has a dredging depth of 1.75 meters and a maximum horizontal reach of 3.16 meters.

What is the minimum bucket capacity of the New Holland E10SR mini excavator?

The minimum bucket capacity of the New Holland E10SR is 0.02 cubic meters.

What operator safety features does the New Holland E10SR have?

The New Holland E10SR is equipped with a roll-over bar for driver protection.
