NR 0.8 Neumeier excavator specs & dimensions (2011 - 2020)

Neumeier NR 0.8 is a mini excavator manufactured since 2011. It has a weight of 1.1 tons and a track width of 180 mm. The transpor…

Neumeier NR 0.8 is a mini excavator manufactured since 2011. It has a weight of 1.1 tons and a track width of 180 mm. The transport dimensions are 2.8 meters in length, 0.76 meters in width, and 2.3 meters in height. The maximum bucket capacity is 0.02 cubic meters. Special equipment includes a blade, rubber track, and track adjustment.

Mini Excavators Neumeier NR 0.8
Mini Excavators Neumeier NR 0.8
Mini Excavators Neumeier NR 0.8
Mini Excavators Neumeier NR 0.8
Mini Excavators Neumeier NR 0.8
Mini Excavators Neumeier NR 0.8
Mini Excavators Neumeier NR 0.8
Mini Excavators Neumeier NR 0.8
Mini Excavators Neumeier NR 0.8
Mini Excavators Neumeier NR 0.8
Mini Excavators Neumeier NR 0.8
Mini Excavators Neumeier NR 0.8

Technical specs - NR 0.8 Neumeier

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.1 t
Transport length
2.8 m
Transport width
0.76 m
Transport height
2.3 m
Bucket capacity max.
0.02 m³
Track width
180 mm
Driver protection
Ü
Max. Reach horizontal
2.83 m
Dredging depth
1.41 m
Tear-out force
4.8 kN
Model series
NR
Engine manuf.
Yanmar
Engine type
2TNV70
Engine power
7.3 kW
Displacement
0.569 l
Revolutions at max torque
2400 rpm

More technical details, like: bucket capacity, bucket capacity min., bucket width, standard tyres, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Neumeier NR 0.8 FAQ

When was the Neumeier NR 0.8 manufactured?

The Neumeier NR 0.8 was first produced in 2011.

How much does the Neumeier NR 0.8 weigh?

The Neumeier NR 0.8 weighs 1.1 tons.

What are the transport dimensions of the Neumeier NR 0.8 mini excavator?

The Neumeier NR 0.8 has a transport length of 2.8 meters, a transport width of 0.76 meters, and a transport height of 2.3 meters.

What is the track width of the Neumeier NR 0.8 mini excavator?

The Neumeier NR 0.8 mini excavator has a track width of 180 mm.

What are the dredging depth and maximum horizontal reach of the Neumeier NR 0.8 mini excavator?

The Neumeier NR 0.8 mini excavator has a dredging depth of 1.41 meters and a maximum horizontal reach of 2.83 meters.

What is the tear-out force of the Neumeier NR 0.8 mini excavator?

The Neumeier NR 0.8 mini excavator has a tear-out force of 4.8 kN.

What is the maximum bucket capacity of the Neumeier NR 0.8 mini excavator?

The Neumeier NR 0.8 mini excavator has a maximum bucket capacity of 0.02 cubic meters.

What operator safety and support features does the Neumeier NR 0.8 have?

The Neumeier NR 0.8 is equipped with a roll-over bar for driver protection.
