M 28 U Messersi excavator specs & dimensions (2007 - 2009)

Messersi M 28 U is a Mini Excavator manufactured from 2007 to 2009, with a weight of 2.8 t. It features a track width of 300 mm, a…

Messersi M 28 U is a Mini Excavator manufactured from 2007 to 2009, with a weight of 2.8 t. It features a track width of 300 mm, a transport length of 4.32 m, a transport width of 1.62 m, and a transport height of 2.5 m. The bucket capacity is a minimum of 0.064 m³. Special equipment includes a blade and rubber track.

Mini Excavators Messersi M 28 U

Technical specs - M 28 U Messersi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.8 t
Transport length
4.32 m
Transport width
1.62 m
Transport height
2.5 m
Bucket capacity min.
0.064 m³
Track width
300 mm
Driver protection
KbR
Model series
M
Engine manuf.
Kubota
Engine type
D1703M
Engine power
25.7 kW
Displacement
1.826 l
No. of cylinders
3

More technical details, like: bucket capacity, bucket capacity max., bucket width, standard tyres, max. reach horizontal, dredging depth, tear-out force, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Messersi M 28 U FAQ

When was the Messersi M 28 U manufactured?

The Messersi M 28 U was manufactured from 2007 to 2009.

How much does the Messersi M 28 U weigh?

The Messersi M 28 U weighs 2.8 tons.

What are the transport dimensions of the Messersi M 28 U mini excavator?

The Messersi M 28 U has a transport length of 4.32 meters, a transport width of 1.62 meters, and a transport height of 2.5 meters.

What is the track width of the undercarriage on the Messersi M 28 U mini excavator?

The Messersi M 28 U mini excavator has a track width of 300 mm.

What is the minimum bucket capacity of the Messersi M 28 U mini excavator?

The minimum bucket capacity of the Messersi M 28 U mini excavator is 0.06 cubic meters.

What operator safety and support features does the Messersi M 28 U have?

The Messersi M 28 U is equipped with a cabin that includes ROPS for driver protection.
