M 16 BV Messersi excavator specs & dimensions (1995 - 2004)

Messersi M 16 BV is a mini excavator manufactured from 1995 to 2004. It has a weight of 1.63 tons and a track width of 230 mm. The…

Messersi M 16 BV is a mini excavator manufactured from 1995 to 2004. It has a weight of 1.63 tons and a track width of 230 mm. The transport dimensions are 3.7 meters in length, 0.99 meters in width, and 2.25 meters in height. The bucket capacity is a minimum of 0.036 cubic meters. Special equipment includes a blade and rubber tracks.

Mini Excavators Messersi M 16 BV

Technical specs - M 16 BV Messersi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.63 t
Transport length
3.7 m
Transport width
0.99 m
Transport height
2.25 m
Bucket capacity min.
0.036 m³
Track width
230 mm
Driver protection
KbR
Model series
M
Engine manuf.
Perkins
Engine type
403C-11
Engine power
19.5 kW

More technical details, like: bucket capacity, bucket capacity max., bucket width, standard tyres, max. reach horizontal, dredging depth, tear-out force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

More technical details, like: bucket capacity, bucket capacity max., bucket width, standard tyres, max. reach horizontal, dredging depth, tear-out force, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Messersi M 16 BV FAQ

When was the Messersi M 16 BV manufactured?

The Messersi M 16 BV was manufactured from 1995 to 2004.

How much does the Messersi M 16 BV weigh?

The Messersi M 16 BV weighs 1.63 tons.

What are the transport dimensions of the Messersi M 16 BV mini excavator?

The Messersi M 16 BV has a transport length of 3.7 meters, a transport width of 0.99 meters, and a transport height of 2.25 meters.

What is the undercarriage specification of the Messersi M 16 BV mini excavator?

The Messersi M 16 BV mini excavator has a track width of 230 mm.

What is the minimum bucket capacity of the Messersi M 16 BV mini excavator?

The minimum bucket capacity of the Messersi M 16 BV is 0.04 cubic meters.

What operator safety features does the Messersi M 16 BV offer?

The Messersi M 16 BV provides operator safety with a cabin equipped with ROPS (Roll-Over Protective Structure).

How much is a Messersi M 16 BV Mini excavator (1995u20132004) worth?

The residual value of the Messersi M 16 BV depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
