KX019-4 SI Kubota excavator specs & dimensions (2022 - 2026)

Kubota KX019-4 SI is a mini excavator manufactured since 2022, with a weight of 1.85 tons. It features a track width of 230 mm, a …

Kubota KX019-4 SI is a mini excavator manufactured since 2022, with a weight of 1.85 tons. It features a track width of 230 mm, a transport length of 3.86 meters, a transport width of 1.3 meters, and a transport height of 2.33 meters. The machine has a tear-out force of 15.9 kN, a dredging depth of 2.58 meters, and a maximum horizontal reach of 4.12 meters. The bucket width is 0.47 meters, and the bucket capacity is 0.04 cubic meters.

Mini Excavators Kubota KX019-4 SI

Technical specs - KX019-4 SI Kubota

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.85 t
Transport length
3.86 m
Transport width
1.3 m
Transport height
2.33 m
Bucket capacity
0.04 m³
Bucket width
0.47 m
Track width
230 mm
Driver protection
FD
Max. Reach horizontal
4.12 m
Dredging depth
2.58 m
Tear-out force
15.9 kN
Model series
KX
Engine manuf.
Kubota
Engine type
WG972-L-E4-BH1
Engine power
14.5 kW
Displacement
0.96 l
No. of cylinders
3
Cylinder bore x stroke
74.5x73.6 mm

More technical details, like: bucket capacity min., bucket capacity max., standard tyres, dimension lxwxh, revolutions at max torque, max. torque, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kubota KX019-4 SI FAQ

When was the Kubota KX019-4 SI manufactured?

The Kubota KX019-4 SI was first produced in 2022.

How much does the Kubota KX019-4 SI weigh?

The Kubota KX019-4 SI weighs 1.85 tons.

What are the transport dimensions of the Kubota KX019-4 SI mini excavator?

The Kubota KX019-4 SI has a transport length of 3.86 meters, a transport width of 1.3 meters, and a transport height of 2.33 meters.

What is the track width of the Kubota KX019-4 SI's undercarriage?

The Kubota KX019-4 SI has a track width of 230 mm.

What are the excavation performance specifications of the Kubota KX019-4 SI mini excavator?

The Kubota KX019-4 SI mini excavator has a dredging depth of 2.58 meters and a maximum horizontal reach of 4.12 meters.

What is the tear-out force of the Kubota KX019-4 SI mini excavator?

The Kubota KX019-4 SI mini excavator has a tear-out force of 15.9 kN.

What are the specifications of the primary work tool bucket on the Kubota KX019-4 SI?

The primary work tool bucket of the Kubota KX019-4 SI has a capacity of 0.04 cubic meters and a width of 0.47 meters.

What operator safety and support features does the Kubota KX019-4 SI have?

The Kubota KX019-4 SI is equipped with a canopy for driver protection.

How much is a Kubota KX019-4 SI Mini excavator (2022u20132025) worth?

The residual value of the Kubota KX019-4 SI depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
