PC50UU Komatsu excavator specs & dimensions (1988 - 1995)

Komatsu PC50UU is a mini excavator manufactured from 1988 to 1995. It has a weight of 5.18 tons and a track width of 400 mm. The t…

Komatsu PC50UU is a mini excavator manufactured from 1988 to 1995. It has a weight of 5.18 tons and a track width of 400 mm. The transport dimensions are 5.95 meters in length, 2 meters in width, and 2.42 meters in height. The tear-out force is 35.3 kN, and the bucket capacity is 0.22 cubic meters. It is equipped with a rubber track.

Mini Excavators Komatsu PC50UU

Visit Komatsu live at

Technical specs - PC50UU Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5.18 t
Transport length
5.95 m
Transport width
2 m
Transport height
2.42 m
Bucket capacity
0.22 m³
Track width
400 mm
Driver protection
KbR
Tear-out force
35.3 kN
Model series
PC
Engine manuf.
Komatsu
Engine type
3D95S
Engine power
28.3 kW
Displacement
2.02 l
Revolutions at max torque
2500 rpm
No. of cylinders
3
Cylinder bore x stroke
95x95 mm

More technical details, like: bucket capacity min., bucket capacity max., bucket width, standard tyres, max. reach horizontal, dredging depth, dimension lxwxh, max. torque, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Komatsu PC50UU FAQ

When was the Komatsu PC50UU manufactured?

The Komatsu PC50UU was manufactured from 1988 to 1995.

How much does the Komatsu PC50UU weigh?

The Komatsu PC50UU weighs 5.18 tons.

What are the transport dimensions of the Komatsu PC50UU mini excavator?

The Komatsu PC50UU has a transport length of 5.95 meters, a transport width of 2 meters, and a transport height of 2.42 meters.

What is the track width of the Komatsu PC50UU's undercarriage?

The Komatsu PC50UU has a track width of 400 mm.

What is the tear-out force of the Komatsu PC50UU mini excavator?

The Komatsu PC50UU mini excavator has a tear-out force of 35.3 kN.

What is the bucket capacity of the Komatsu PC50UU mini excavator?

The bucket capacity of the Komatsu PC50UU mini excavator is 0.22 cubic meters.

What operator safety and support features does the Komatsu PC50UU have?

The Komatsu PC50UU is equipped with a cabin that includes ROPS for driver protection.

How much is a Komatsu PC50UU Mini excavator (1988u20131995) worth?

The residual value of the Komatsu PC50UU depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
