PC22MR-3 Komatsu excavator specs & dimensions (2011 - 2021)

Model rating
9,00 / 10

Komatsu PC22MR-3 is a mini excavator manufactured from 2011 to 2021, with a weight of 2.55 tons. It features a track width of 250 …

Komatsu PC22MR-3 is a mini excavator manufactured from 2011 to 2021, with a weight of 2.55 tons. It features a track width of 250 mm, a transport length of 3.86 meters, a transport width of 1.45 meters, and a transport height of 2.485 meters. The machine has a dredging depth of 2.28 meters and a maximum horizontal reach of 4 meters. The bucket width is 0.55 meters, with a bucket capacity ranging from 0.035 m³ to 0.085 m³. It is equipped with a rubber track.

Mini Excavators Komatsu PC22MR-3
Mini Excavators Komatsu PC22MR-3
Mini Excavators Komatsu PC22MR-3
Mini Excavators Komatsu PC22MR-3
Mini Excavators Komatsu PC22MR-3
Mini Excavators Komatsu PC22MR-3
Mini Excavators Komatsu PC22MR-3
Mini Excavators Komatsu PC22MR-3
Mini Excavators Komatsu PC22MR-3
Mini Excavators Komatsu PC22MR-3
Mini Excavators Komatsu PC22MR-3
Mini Excavators Komatsu PC22MR-3
Mini Excavators Komatsu PC22MR-3
Mini Excavators Komatsu PC22MR-3

Visit Komatsu live at

Technical specs - PC22MR-3 Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.55 t
Transport length
3.86 m
Transport width
1.45 m
Transport height
2.485 m
Bucket capacity min.
0.035 m³
Bucket capacity max.
0.085 m³
Bucket width
0.55 m
Track width
250 mm
Max. Reach horizontal
4 m
Dredging depth
2.28 m
Tear-out force
13.9 kN
Model series
PC
Engine manuf.
Komatsu
Engine type
3D76E
Engine power
15.7 kW
Displacement
1.115 l
Revolutions at max torque
2500 rpm
Max. torque
66.7 Nm
No. of cylinders
3

More technical details, like: bucket capacity, standard tyres, driver protection, dimension lxwxh, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
Yes
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Komatsu PC22MR-3 FAQ

When was the Komatsu PC22MR-3 manufactured?

The Komatsu PC22MR-3 was manufactured from 2011 to 2021.

How much does the Komatsu PC22MR-3 weigh?

The Komatsu PC22MR-3 weighs 2.55 tons.

What are the transport dimensions of the Komatsu PC22MR-3 mini excavator?

The Komatsu PC22MR-3 has a transport length of 3.86 meters, a transport width of 1.45 meters, and a transport height of 2.49 meters.

What is the track width of the Komatsu PC22MR-3 mini excavator?

The Komatsu PC22MR-3 mini excavator has a track width of 250 mm.

What are the excavation performance specifications of the Komatsu PC22MR-3?

The Komatsu PC22MR-3 has a dredging depth of 2.28 meters and a maximum horizontal reach of 4 meters.

What is the tear-out force of the Komatsu PC22MR-3 mini excavator?

The Komatsu PC22MR-3 mini excavator has a tear-out force of 13.9 kN.

What are the bucket specifications of the Komatsu PC22MR-3 mini excavator?

The Komatsu PC22MR-3 has a bucket width of 0.55 meters, with a maximum capacity of 0.09 cubic meters and a minimum capacity of 0.04 cubic meters.
