HD19VXT Kato Imer excavator specs & dimensions (2023 - 2026)

Weight: 1.905t – Transport length: 3.665m – Transport width: 0.98m – Transport height: 2.34m – Bucket capacity: 0.044m³ – Bucket c…

Weight: 1.905t – Transport length: 3.665m – Transport width: 0.98m – Transport height: 2.34m – Bucket capacity: 0.044m³ – Bucket capacity min.: 0.044m³

Check out detailed specifications, information and technical data for Kato Imer HD19VXT excavator manufactured between 2023 - 2026. Get more in-depth insight with Kato Imer HD19VXT digger specifications. See information, like: Weight: 1.905t – Transport length: 3.665m – Transport width: 0.98m – Transport height: 2.34m – Bucket capacity: 0.044m³ – Bucket capacity min.: 0.044m³ and more.

Mini Excavators Kato Imer HD19VXT

Technical specs - HD19VXT Kato Imer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.905 t
Transport length
3.665 m
Transport width
0.98 m
Transport height
2.34 m
Bucket capacity
0.044 m³
Bucket capacity min.
0.044 m³
Bucket width
0.4 m
Track width
230 mm
Max. Reach horizontal
4.08 m
Dredging depth
2.46 m
Tear-out force
15.7 kN
Model series
V
Engine manuf.
Yanmar
Engine type
3TNV70
Engine power
10.5 kW
Displacement
0.854 l
Revolutions at max torque
2300 rpm
No. of cylinders
3
Cylinder bore x stroke
70x74 mm
Emission level
Tier 4

More technical details, like: bucket capacity max., standard tyres, driver protection, dimension lxwxh, max. torque are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
Yes
Rubber track
Yes
Blade
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kato Imer HD19VXT FAQ

When was the Kato Imer HD19VXT manufactured?

The Kato Imer HD19VXT was first produced in 2023.

How much does the Kato Imer HD19VXT weigh?

The Kato Imer HD19VXT weighs 1.91 tons.

What are the transport dimensions of the Kato Imer HD19VXT mini excavator?

The Kato Imer HD19VXT has a transport length of 3.67 meters, a transport width of 0.98 meters, and a transport height of 2.34 meters.

What is the track width of the Kato Imer HD19VXT mini excavator?

The Kato Imer HD19VXT mini excavator has a track width of 230 mm.

What are the excavation performance specifications of the Kato Imer HD19VXT mini excavator?

The Kato Imer HD19VXT has a dredging depth of 2.46 meters and a maximum horizontal reach of 4.08 meters.

What is the tear-out force of the Kato Imer HD19VXT mini excavator, given that no power rating data is available?

The Kato Imer HD19VXT has a tear-out force of 15.7 kN; no power rating data is available.

What are the bucket specifications of the Kato Imer HD19VXT mini excavator?

The Kato Imer HD19VXT has a bucket capacity of 0.044 cubic meters, a minimum bucket capacity of 0.04 cubic meters, and a bucket width of 0.4 meters.
