55N4 Kato Imer excavator specs & dimensions (2020 - 2023)

Kato Imer 55N4 is a Mini Excavator manufactured since 2020. It has a weight of 5.62 tons and a track width of 400 mm. The transpor…

Kato Imer 55N4 is a Mini Excavator manufactured since 2020. It has a weight of 5.62 tons and a track width of 400 mm. The transport dimensions are 5.86 meters in length, 2 meters in width, and 2.57 meters in height. The machine features a tear-out force of 36.3 kN, a dredging depth of 4.1 meters, and a maximum horizontal reach of 5.98 meters. The bucket width is 0.68 meters with a capacity of 0.18 cubic meters. It is equipped with a diesel particulate filter.

Mini Excavators Kato Imer 55N4

Technical specs - 55N4 Kato Imer

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
5.62 t
Transport length
5.86 m
Transport width
2 m
Transport height
2.57 m
Bucket capacity
0.18 m³
Bucket width
0.68 m
Track width
400 mm
Max. Reach horizontal
5.98 m
Dredging depth
4.1 m
Tear-out force
36.3 kN
Model series
N
Engine manuf.
Yanmar
Engine type
4TNV98C-PIK
Engine power
47.6 kW
Displacement
3.318 l
Revolutions at max torque
2400 rpm
No. of cylinders
4
Cylinder bore x stroke
98x110 mm

More technical details, like: bucket capacity min., bucket capacity max., standard tyres, driver protection, dimension lxwxh, max. torque, emission level are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment
No
Rubber track
No
Blade
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kato Imer 55N4 FAQ

When was the Kato Imer 55N4 manufactured?

The Kato Imer 55N4 was manufactured from 2020 to 2023.

How much does the Kato Imer 55N4 weigh?

The Kato Imer 55N4 weighs 5.62 tons.

What are the transport dimensions of the Kato Imer 55N4 mini excavator?

The Kato Imer 55N4 has a transport length of 5.86 meters, a transport width of 2 meters, and a transport height of 2.57 meters.

What is the track width of the Kato Imer 55N4 mini excavator's undercarriage?

The Kato Imer 55N4 mini excavator has a track width of 400 mm.

What are the excavation performance specifications of the Kato Imer 55N4 mini excavator?

The Kato Imer 55N4 mini excavator has a dredging depth of 4.1 meters and a maximum horizontal reach of 5.98 meters.

What is the tear-out force of the Kato Imer 55N4 mini excavator?

The Kato Imer 55N4 mini excavator has a tear-out force of 36.3 kN.

What are the bucket specifications of the Kato Imer 55N4 mini excavator?

The Kato Imer 55N4 has a bucket capacity of 0.18 cubic meters and a bucket width of 0.68 meters.
