Technical specs - 36C-1 JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 3.7 t

Transport length: 4.8 m

Transport width: 1.55 m

Transport height: 2.482 m

Track width: 300 mm

Driver protection: Kb

Max. Reach horizontal: 5.31 m

Dredging depth: 3.51 m

Tear-out force: 32 kN

Engine manuf.: Perkins

Engine type: 403J-17

Engine power: 18.4 kW

Displacement: 1.496 l

Revolutions at max torque: 1800 rpm

Max. torque: 90.4 Nm

Emission level: V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, model series, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: No
Rubber track: Yes
Blade: Yes
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

JCB 36C-1 FAQ

When was the JCB 36C-1 manufactured?

The JCB 36C-1 was first produced in 2021.

How much does the JCB 36C-1 mini excavator weigh?

The JCB 36C-1 mini excavator weighs 3.7 tons.

What are the transport dimensions of the JCB 36C-1 mini excavator?

The JCB 36C-1 has a transport length of 4.8 meters, a transport width of 1.55 meters, and a transport height of 2.48 meters.

What is the track width of the JCB 36C-1 mini excavator's undercarriage?

The JCB 36C-1 mini excavator has a track width of 300 mm.

What is the excavation performance of the JCB 36C-1 mini excavator?

The JCB 36C-1 mini excavator has a dredging depth of 3.51 meters and a maximum horizontal reach of 5.31 meters.

What is the tear-out force of the JCB 36C-1 mini excavator?

The JCB 36C-1 mini excavator has a tear-out force of 32 kN.

What operator safety features does the JCB 36C-1 have?

The JCB 36C-1 has a driver protection cabin.

How much is a JCB 36C-1 Mini excavator (2021u20132025) worth?

The residual value of the JCB 36C-1 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

JCB 36C-1 overview

Tyres / Tracks

TOUGH TO BEAT FOR COST OF OWNERSHIP.
Minimum downtime with the aid of a screen mounted health check display and an easy-to-clean sloping undercarriage for quick turning. 35z-1/36c-1 MINI EXCAVATOR

Dimensions and weight

Machine model		35Z-1		36C-1
A	Sprocket idler centres	mm	1590
B	Track length on ground	mm		1590
C	Undercarriage overall length – rubber	mm		2048.5
	Undercarriage overall length – steel	mm		2048.5
D	Kingpost clearance	mm		555
E	Tailswing radius (Standard / Heavy counterweight)	mm	900 / 1000		1200 / 1300
F	Overall width of superstructure	mm		1550
G	Height over cab	mm			2482
H	Ground clearance	mm			275
I	Track gauge	mm	1400			1200
J	Width over tracks	mm	1750			1550
K	Transport length with standard dipper	mm	4851			4806
L	Track height	mm			480
M	Counterweight clearance	mm			563

WEIGHTS
Machine model		35Z-1	36C-1
Operating weight*	kg	3556		3759
Shipping** weight	kg	3371	3574
Canopy	kg		-81
Heavy counterweight	kg	246		Fitted
1600 dipper	kg	15		Fitted
No quick hitch or pipework	kg		-53
No lifting kit or HBCVs	kg		-24

DOZER
Machine model		35Z-1		36C-1	35Z-1	36C-1
Dozer type			2-way		4-way
Dozer length	mm		1648		1701
Max height above ground	mm			436		439
Dig depth below ground	mm		416			457
Approach angle	degrees		29		27
Width	mm	1750		1550	1750		1550
Height	mm			357	357
4-way pivot angle	degrees	-	25

			35Z-1 36C-1
	Dipper length	mm	1300	1600		1300	1600
	Boom length	mm			2450
A	Max digging reach	mm	5165	5443	4865	5143
B	Max digging reach on ground	mm	5035	5322		4735	5022
C	Max digging depth – dozer up	mm	3042	3339		3042	3339
	Max digging depth – dozer down	mm	3194	3483		3194	3483
D	Max digging height	mm	4571	4730		4571	4730
E	Max dump height	mm	3378	3537		3378	3537
F	Max height to dipper nose pivot pin	mm	3980	4139		3980	4139
G	Max vertical wallcut depth	mm	1610	1873		1610	1873
H	Min front swing radius (no offset)	mm	2396	2462			2096	2162
	Min front swing radius (fully offset)	mm	1891	1947			1591	1647
I	Boom swing left	degrees				75
J	Boom swing right	degrees			55
	Bucket rotation	degrees			191
	Dipper rotation	degrees			109.2
	Bucket tearout	kN			32.4
	Dipper tearout	kN	22.5	19.7		22.5	19.7
	Slew speed	rpm			8.3

OPERATOR ENVIRONMENT
Machine model		35Z-1	36C-1
Cab/canopy height	mm		1575
Cab/canopy height with FOGS guard LEVEL 1	mm		1595
Cab/canopy length	mm		1261
Cab/canopy width	mm		1043
Door aperture width	mm		479

Other features

TOUGH TO BEAT FOR COMFORT.
Featuring a spacious cab, clear flat floor and hands-free bluetooth radio with media socket, our 35Z-1 and 36C-1 excavator cabins are great work

Safety

TOUGH TO BEAT FOR DURABILITY.
Hoses are routed through the trench end for maximum protection from damage and wear, while O-ring surfaces protect sealed hydraulic connections against leaks.
TOUGH TO BEAT FOR SAFETY.
Seat belt activated green beacon, follow-me home lights, lift overload system and JCB's unique 2GO system all contribute to safer work.

Tables

ENGINE
Machine model	35Z-1 36C-1
Model	EU Stage V / EPA Tier 4 Final Perkins 403J-17
Fuel	Diesel
Cooling	Water cooled
Gross power ISO 14396 kW	18.4 (@ 2200rpm)
Net power kW	15.9 (@ 2000rpm)
Gross torque ISO 14396	Nm	91.9 (@ 1600rpm)
Displacement	cc	1662
Gradeability	degrees	30
Starter motor	kW	2
Battery	volt / amps	12V / 80Ah
Alternator	amps (Air con)	85

UNDERCARRIAGE
Machine model		35Z-1		36C-1
No of top rollers			1
No of bottom rollers			4
Track width rubber (STD)	mm		300
Track width steel	mm		300
Ground bearing pressure (300mm tracks)	kg/cm2	0.316		0.331
Track tensioning			Grease
Travel speed – low	kph		2.8
Travel speed – high	kph		4.5
Tractive effort	kN		25.6

HYDRAULIC SYSTEM
Machine model		35Z-1	36C-1
Pump	cc		38
	Nominal output @ 2000rpm	lpm		76
	Excavator/track main relief pressure	bar		250
	Slew main relief pressure	bar		216
		bar		STD: 190
Auxiliary hydraulic pressure (Low)		ADJ: 120 - 250
	Auxiliary hydraulic pressure (High)	bar		STD: 190 ADJ: 120 - 250
	Auxiliary hydraulic flow (Low)	lpm		30
	Auxiliary hydraulic flow (High)	lpm	70
	Hydraulic pump		Variable Displacement Piston

SERVICE CAPACITIES
Machine model		35Z-1		36C-1
Fuel tank	ltr		50
Engine coolant	ltr		7
Engine oil	ltr		5.2
Hydraulic system	ltr		47.5
Hydraulic tank	ltr		20.3

Load Point	1.5m	2.5m	3.5m	4.5m	Capacity at maximum reach
													中
Height	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side
m	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg
2.5							488	741	536
2.0				816	1084	887	476	830	523
1.5				768	1486	836	461	943	507	310	799	343	310	799	343
1.0							446	1058	491	305	832	338	305	832	338
0.5				706	2016	771	434	1152	478	301	859	334	301	859	334
0.0				698	2063	763	426	1210	470
-0.5	1460	1494	1579	698	2026	762	423	1223	466
-1.0	1847	2115	1948	702	1916	767	424	1177	468
-1.5	1866	2840	1967	713	1713	778	433	1024	477
-2.0	1902	2738	2004	731	1343	798

Height	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side
m	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg
3.0							558	571	604
2.5							578	625	630	379	669	416
2.0							565	719	615	376	687	412
1.5				925	1219	998	548	839	597	370	726	405	333	650	365
1.0				876	1611	946	531	967	579	363	771	398	328	743	361
0.5				843	1882	912	516	1079	563	357	814	392	324	703	356
0.0				827	2012	895	505	1161	552	353	843	387
-0.5	1262	1291	1364	821	2037	889	499	1203	545	351	842	386
-1.0	1721	1761	1861	822	1980	890	498	1194	544
-1.5	2154	2301	2253	830	1839	897	502	1118	548
-2.0	2187	2974	2287	844	1580	912
-2.5	2241	2297	2342	871	1067	942

Height	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side
m	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg
3.0							587	601	579
2.5							621	635	572
2.0							615	703	560
1.5				1014	1045	901	601	791	546	407	650	371	407	650	371
1.0				973	1313	861	587	886	531	402	743	366	402	743	366
0.5				943	1523	830	574	973	518	398	703	361	398	703	361
0.0				924	1648	812	564	1038	508
-0.5	1472	1507	1592	916	1692	803	558	1070	502
-1.0	1978	2024	1859	915	1665	803	557	1057	501
-1.5	2360	2654	1879	921	1560	809	563	970	507
-2.0	2394	2553	1909	936	1342	823
-2.5	1685	1724	1822

Height	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side	Dozer Up	Dozer Down	Over Side
m	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg	kg
3.0							587	601	635
2.5							621	635	671
2.0							687	703	661
1.5				1022	1045	1056	706	791	646	483	650	445	483	650	445
1.0				1141	1313	1016	692	886	631	479	743	440	479	743	440
0.5				1110	1523	985	679	973	618	474	703	435	474	703	435
0.0				1091	1648	967	669	1038	608
-0.5	1472	1507	1592	1083	1692	958	663	1070	602
-1.0	1978	2024	2139	1082	1665	958	663	1057	601
-1.5	2594	2654	2220	1088	1560	964	668	970	607
-2.0	2495	2553	2251	1103	1342	978
-2.5	1685	1724	1822
