Technical specs - 35Z HD JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 3.79 t
- Transport length
- 4.85 m
- Transport width
- 1.75 m
- Transport height
- 2.48 m
- Track width
- 300 mm
- Driver protection
- KbR
- Max. Reach horizontal
- 5.04 m
- Dredging depth
- 3.04 m
- Engine manuf.
- Perkins
- Engine type
- 403J-17
- Engine power
- 18.9 kW
- Displacement
- 1.662 l
- Revolutions at max torque
- 1600 rpm
- Max. torque
- 91.9 Nm
- Emission level
- EU V / EPA Tier 4 Final
More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., bucket width, standard tyres, tear-out force, model series, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with standard bucket
Special equipment
- Track adjustment
-
No
- Rubber track
-
No
- Blade
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
Download datasheets (PDF)
JCB 35Z HD FAQ
How much does the JCB 35Z HD weigh?
What are the transport dimensions of the JCB 35Z HD mini excavator?
What is the track width of the JCB 35Z HD mini excavator?
What are the excavation performance specifications of the JCB 35Z HD mini excavator?
What operator safety and support features does the JCB 35Z HD have?
How much is a JCB 35Z HD Mini excavator (2022u20132025) worth?
