Technical specs - R55-9A Hyundai
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 5.65 t
- Transport length
- 5.9 m
- Transport width
- 1.92 m
- Transport height
- 2.55 m
- Bucket capacity
- 0.18 m³
- Bucket capacity min.
- 0.07 m³
- Bucket capacity max.
- 0.18 m³
- Bucket width
- 0.74 m
- Track width
- 400 mm
- Driver protection
- KbR
- Max. Reach horizontal
- 6.15 m
- Dredging depth
- 3.82 m
- Tear-out force
- 28.4 kN
- Model series
- 9A
- Engine manuf.
- Yanmar
- Engine type
- 4TNV98C
- Engine power
- 49.9 kW
- Displacement
- 3.319 l
- Revolutions at max torque
- 1560 rpm
- Max. torque
- 235 Nm
- No. of cylinders
- 4
- Cylinder bore x stroke
- 98x110 mm
- Emission level
- V
More technical details, like: standard tyres, dimension lxwxh are available in the full technical specs.
Basic model with standard bucket
Special equipment
- Track adjustment
-
No
- Rubber track
-
Yes
- Blade
-
Yes
- Aircondition
-
Yes
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
Download datasheets (PDF)
Hyundai R55-9A FAQ
How much does the Hyundai R55-9A weigh?
What are the transport dimensions of the Hyundai R55-9A mini excavator?
What is the track width of the Hyundai R55-9A mini excavator's undercarriage?
What are the excavation performance specifications of the Hyundai R55-9A mini excavator?
What is the tear-out force of the Hyundai R55-9A mini excavator?
What are the bucket specifications of the Hyundai R55-9A mini excavator?
What operator safety and support features does the Hyundai R55-9A have?
How much is a Hyundai R55-9A Mini excavator (2020u20132025) worth?
