Technical specs - HX10A Hyundai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.09 t

Transport length: 2.75 m

Transport width: 0.73 m

Transport height: 2.26 m

Bucket capacity: 0.015 m³

Bucket capacity min.: 0.015 m³

Bucket capacity max.: 0.015 m³

Bucket width: 0.25 m

Track width: 180 mm

Driver protection: Ü

Max. Reach horizontal: 3.05 m

Dredging depth: 1.77 m

Tear-out force: 4.51 kN

Model series: 10A

Engine manuf.: Yanmar

Engine type: 3TNV70

Engine power: 9.9 kW

Displacement: 0.85 l

Revolutions at max torque: 1500 rpm

Max. torque: 52 Nm

No. of cylinders: 3

Cylinder bore x stroke: 70x74 mm

Emission level: V

More technical details, like: standard tyres, dimension lxwxh are available in the full technical specs.

Basic model with standard bucket

Special equipment

Track adjustment: Yes
Rubber track: Yes
Blade: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Hyundai HX10A FAQ

When was the Hyundai HX10A manufactured?

The Hyundai HX10A was first produced in 2019.

How much does the Hyundai HX10A mini excavator weigh?

The Hyundai HX10A mini excavator weighs 1.09 tons.

What are the transport dimensions of the Hyundai HX10A mini excavator?

The Hyundai HX10A has a transport length of 2.75 meters, a transport width of 0.73 meters, and a transport height of 2.26 meters.

What is the track width of the Hyundai HX10A mini excavator?

The Hyundai HX10A mini excavator has a track width of 180 mm.

What are the excavation performance specifications of the Hyundai HX10A mini excavator?

The Hyundai HX10A mini excavator has a dredging depth of 1.77 meters and a maximum horizontal reach of 3.05 meters.

What is the tear-out force of the Hyundai HX10A mini excavator?

The Hyundai HX10A mini excavator has a tear-out force of 4.51 kN.

What are the bucket specifications of the Hyundai HX10A mini excavator?

The Hyundai HX10A mini excavator has a bucket capacity of 0.015 mu00b3, a maximum bucket capacity of 0.02 mu00b3, a minimum bucket capacity of 0.02 mu00b3, and a bucket width of 0.25 meters.

What operator safety and support features does the Hyundai HX10A have?

The Hyundai HX10A is equipped with a roll-over bar for driver protection.

How much is a Hyundai HX10A Mini excavator (2019u20132025) worth?

The residual value of the Hyundai HX10A depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Hyundai HX10A overview

Engine / Driveline and transmission

HYDRAULIC POWER UNIT
THE POWERFUL 3 CPYLINDER ENGINE GUARANTEE'S AMPLE POWER FOR A WIDE RANGE OF ACTIVITY HX10A is operated with optimal fuel efficiency and minimum emissions to ensure compliance with environmental regulations. This small workhorse has been designed to provide extreme versatility and operate with maximum efficiency every day, in nearly all environments.

Tyres / Tracks

THE SMALLEST BUT MOST STRONGEST
HX10A, Hyundai's smallest model, can work through any door and building with retractable dozer and track guard rod. The size of the machine is ideal for demolition and rebuild inside buildings, with standard break-up piping. Even HX10A can pass all doors using the fold-in undercarriage and a collapsible ROPS stick. Turn to your dealer to find out how the HX10A can help you work more efficiently, productively and safely!
DURABLE DESIGN OF BOOM & ARM
The top mounted boom cylinder as well as the hoses routed within the boom provide in addition to avoiding damage. Breaker piping is standard, ideal machine for using hammers in interior

Dimensions and weight

Load point height m (in)	Load radius	At max. reach
2.5 m (98 in)	2.0 m (79 in)	1.5 m (59 in)	1.0 m (39 in)	Capacity	Reach
									m (ft)
2.4 m	kg									216	216	1.41
(94 in)	lb									477	477	(4.61)
2.0 m	kg		203	170						205	167	2.03
(79 in)	lb		448	376						453	367	(6.64)
1.5 m	kg		189	172						163	126	2.40
(59 in)	lb		416	378						358	277	(7.86)
1.0 m	kg	151 166	212	166	247		247			142	109	2.59
(39 in)	lb	332 255	469	366	544		544			314	240	(8.49)
0.5 m	kg	147 113	204	158	311	241			135	103	2.65
(20 in)	lb	325 248	450	347	685	531			298	227	(8.7)
Ground	kg	145 110	197	150	296	226	570	431	137	104	2.60
Line	lb	319 242	434	332	653	499	1	257"	951	303	230	(8.52)
-0.5 m	kg		194	148	292	222	561	433	146	115	2.41
(-20 in)	lb		428	325	644	490	1	236"	955	323	253	(7.91)
-1.0 m	kg		149	149	243	225	418	418	138	138	2.05
(-39 in)	lb		328	328	536	497	922	922	304	304	(6.73)

Height	2	261 mm (89 in)"
Upper carriage width	730 mm (29 in)
Width with retracted / Extended telescopic travel gear	700 / 860 mm (28 / 34 in)
Width with stabilizer blade folded in/out	700 / 860 mm (28 / 34 in)
Transport length	2	747 (9')"
Max. digging depth	1	766 mm (70 in)"
Stick length	890 mm (35 in)
Max. vertical digging depth	1	320 mm (52 in)"
Max. digging height	2	853 mm (9' - 4')"
Max. tilt-out height	2	008 mm (79 in)"
Max. digging radius	3	092 mm (10' - 2')"
Max. reach at ground level	3	046 mm (10')"
Max. breakout force at bucket tooth	8.9 kN (2	001 lbf)"
Max. tearout force	4.5 kN (1	012 lbf)"
Min. tail end slewing radius	747 mm (29 in)
Max. tail end lateral projection of upper carriage	90。rotation With retracted / Extended telescopic travel gear With stabilizer blade folded in/out"	397 / 317 mm (16 / 12 in) 397 / 317 mm (16 / 12 in)
Max. boom displacement to bucket center (right side)	287 mm (11 in)
Max. boom displacement to bucket center (left side)	242 mm (10 in)

Height	Dimensions model with rollbar	2	261 mm (89 in)"
Dimensions model without rollbar	1	436 mm (57 in)"
Upper carriage width	730 mm (29 in)
Width with retracted / extended telescopic travel gear	700 / 860 mm (28 / 34 in)
Width with stabilizer blade folded in / out	700 / 860 mm (28 / 34 in)
Transport length	2	747 (9＇)"
Max. digging depth	1	766 mm (70 in)"
Stick length	890 mm (35 in)
Max. vertical digging depth	1	320 mm (52 in)"
Max. digging height	2	853 mm (9＇ - 4＂)"
Max. tilt-out height	2	008 mm (79 in)"
Max. digging radius	3	092 mm (10＇ - 2＂)"
Max. reach at ground level	3	046 mm (10＇)"

Operating weight*	1	087 kg (2.396 lbs)"
Transport weight**	990 kg (2	182 lbs)"
Track Width	180 mm (7 in)
Ground pressure	0.24 kg/cm2 (3.4 lbs/in2 )

Other features

EASY MAINTENANCE AND SERVICES
WIDE OPEN ENGINE COVER PROVIDS EASY ACCESS FOR SERVING TASKS Operators can easily open the engine cover and check equipment more conveniently.

Tables

WORK & SAFETY	STD	OPT
Hydarulic retractable undercarriage	●
180 mm Rubber track	●
ROPS Foldable safety bar	●
Bucket (250 mm)		●
Bucket (300 mm)		●
Bucket (400 mm)		●
Bucket (700 mm)		●
Foldable dozer blade	●
Work light	●

HYDRAULIC SYSTEM	STD	OPT
1 way breaker piping	●
2 way auxiliary hydarulics		●
Bio oil		●
Dual power ready		●
Hydarulic power unit		●

	liter	US gal	UK gal
Fuel tank	7	1.85	1.54
Engine coolant	2	9"	0.77	0.64
Engine oil	2	5"	0.66	0.55
Hydraulic tank	13	8"	3.65	3.03

ENGINE
Maker / Model	Yanmar 3TNV70 / Stage V
Type	Water-cooled four stroke diesel engine 3-cylinder indirect injection
Gross Power	9.9 kW (13.3 HP) at 2	100 rpm"
Net Power (ISO)	9.6 kW (13 HP) at 2	100 rpm"
Max. Torque	5.3 kgf·m (38 lbf·ft) at 1	500 rpm"
Bore x stroke	70 x 74 mm (2.8＂x 2.9＂)
Piston displacement	854 cc (52.3 cu in)
Battery	12 V 30 Ah
Starting motor	12 V - 1	1 kW"
Alternator	12 V - 20 A

DRIVES & BRAKES
Max. travel speed (high) / (low)	1.82 km/h (1.1 mph)
Maximum gradeability	0°/ 58 %

MAIN PUMP
Type	Twin gear pump 2 x 4 cm3 (2 x 0.24 in3 )
Max. flow	2 x 10.7 ℓ/min at 2	675 rpm (2 x 2.8 gpm at 2	675 rpm)"
Sub-pump for pilot circuit	n/a
HYDRAULIC MOTORS
Travel	Slow-running drive motor without gears and with internal leak oil drain
Swing	Slow-running swing motor without gears with automatic break
RELIEF VALVE SETTING
Travel	170 ±3 bar (2	466 psi)"
Swing circuit	70 bar (1	015 psi)"
OPERATOR’S CABIN
Sound power level (LWA)1	93 dB (A)
